FORK LEGS (W/ PAINT) для Ktm LC4 400 Dual Sport - 2000 года выпуска
-
№АртикулНазвание
-
158301408000 SCREW CAP CPL.COMPRESS DAMPINGSCREW CAP CPL.COMPRESS DAMPING
-
258301409000 SCREW CAP CPL. REBOUND DAMPINGSCREW CAP CPL. REBOUND DAMPING
-
30770400020 O-RING 40,00X2,00O-RING 40,00X2,00
-
558301414000 GASKET SET WITH SLIDING BUSHGASKET SET WITH SLIDING BUSH
-
658301423000 SPRING RETAINER WITH SLOTSPRING RETAINER WITH SLOT
-
858301415000 REPAIR KIT SHAFT SEAL RINGSREPAIR KIT SHAFT SEAL RINGS
-
1658301429000 CIRCLIP D=50MMCIRCLIP D=50MM
-
2258401003000 FORK TUBE D=50MM/L=698MMFORK TUBE D=50MM/L=698MM
-
2458301419000 WASHER 32X45X2WASHER 32X45X2
-
3054701021038 SPRING 3,8 N/MM SETSPRING 3,8 N/MM SET
-
3054701021040 SPRING 4,0 N/MM SETSPRING 4,0 N/MM SET
-
3054701021042 SPRING 4,2 N/MM SETSPRING 4,2 N/MM SET
-
3054701021044 SPRING 4,4 N/MM SETSPRING 4,4 N/MM SET
-
3054701021046 SPRING 4,6 N/MM SETSPRING 4,6 N/MM SET
-
3054701021048 SPRING 4,8 N/MM SETSPRING 4,8 N/MM SET
-
3254701016000 RING 35X41,5X2,5RING 35X41,5X2,5
-
3454701022000 BUSHING 44,5X35X80BUSHING 44,5X35X80
-
3554701018000 SLIDING BUSH HYDRO-STOP L=73,5SLIDING BUSH HYDRO-STOP L=73,5
-
3654701004000 OUTER TUBE L=439MMOUTER TUBE L=439MM
-
3858201006100 AXLE CLAMP L/S 300MM M8AXLE CLAMP L/S 300MM M8
-
4054701007000 AXLE CLAMP R/S EXTREME M8AXLE CLAMP R/S EXTREME M8
-
410015080253 HH COLLAR SCREW M 8X25 WS=10HH COLLAR SCREW M 8X25 WS=10
-
420015080203 HH COLLAR SCREW M 8X20 WS=10HH COLLAR SCREW M 8X20 WS=10
-
4358038032100 SEAL RING 8X12X2 (COPPER)SEAL RING 8X12X2 (COPPER)
-
4458301006050 CLAMPING PLATE 13,5X42,5CLAMPING PLATE 13,5X42,5
-
70306007 FORK OIL SAE5 5 LITERFORK OIL SAE5 5 LITER
