CYLINDER HEAD для Ktm LC4 640 Super Moto - 2001 года выпуска
-
№АртикулНазвание
-
158436020000 CYLINDER HEAD CPL.CYLINDER HEAD CPL.
-
249030090000 DOWEL 9,8 X 7 X 10DOWEL 9,8 X 7 X 10
-
358036065100 CU-SEAL RING 6 X 10 X 2CU-SEAL RING 6 X 10 X 2
-
458036152600 VALVE COVER FRONTVALVE COVER FRONT
-
558036052000 VALVE COVER REARVALVE COVER REAR
-
658036053000 VALVE COVER GASKETVALVE COVER GASKET
-
758330036000 CYLINDER HEAD GASKET 101,3 MMCYLINDER HEAD GASKET 101,3 MM
-
80603061001 CU-SEAL RING DIN7603- 6X10X1CU-SEAL RING DIN7603- 6X10X1
-
90912060353 AH SCREW DIN0912-M 6X35AH SCREW DIN0912-M 6X35
-
110912060253 AH SCREW DIN0912-M 6X25AH SCREW DIN0912-M 6X25
-
1249030028000 COLLAR NUT M8 - 8MM HIGHCOLLAR NUT M8 - 8MM HIGH
-
1354330043000 STUD DIN0835-M 8X40STUD DIN0835-M 8X40
-
1458036098000 CU-SEAL RING 10 X 20 X 1CU-SEAL RING 10 X 20 X 1
-
01458036099100 COLLAR SCREW M10X80 SK13MMCOLLAR SCREW M10X80 SK13MM
-
1542011252000 TEMPERATURE SWITCH VDOTEMPERATURE SWITCH VDO
-
180993012000 CIRCLIP DIN7993A-RW12CIRCLIP DIN7993A-RW12
-
01858036026600 VALVE GUIDE INTAKEVALVE GUIDE INTAKE
-
1958036126600 VALVE GUIDE EXHAUSTVALVE GUIDE EXHAUST
-
3058036040000 EXHAUST FLANGE R/SEXHAUST FLANGE R/S
-
3158036140000 EXHAUST FLANGE L/SEXHAUST FLANGE L/S
-
3258036041000 EXHAUST FLANGE GASKETEXHAUST FLANGE GASKET
-
3458336024000 PLUG SLS BOREPLUG SLS BORE
-
3558436054000 CU-SEAL RING 12 X 16 X 2CU-SEAL RING 12 X 16 X 2
-
3958136042040 INTAKE FLANGE D=40MMINTAKE FLANGE D=40MM
-
4158136043000 INTAKE FLANGE GASKETINTAKE FLANGE GASKET
-
4258436044000 INTAKE BOOT FOR MIKUNI CARBU.INTAKE BOOT FOR MIKUNI CARBU.
-
4556530061000 CLAMP SM12/A60CLAMP SM12/A60
-
490912060163 AH SCREW DIN0912-M 6X16AH SCREW DIN0912-M 6X16
-
500991060203 FLAT HEAD SCREW DIN7991-M 6X20FLAT HEAD SCREW DIN7991-M 6X20
-
510912060203 AH SCREW DIN0912-M 6X20AH SCREW DIN0912-M 6X20
-
520912060253 AH SCREW DIN0912-M 6X25AH SCREW DIN0912-M 6X25
-
5351005074000 RETAINING PLATERETAINING PLATE
-
540912060501 AH SCREW DIN0912-M 6X50AH SCREW DIN0912-M 6X50
-
550912060551 AH SCREW DIN0912-M 6X55AH SCREW DIN0912-M 6X55
-
560912060653 AH SCREW DIN0912-M 6X65AH SCREW DIN0912-M 6X65
-
570912060703 AH SCREW DIN0912-M 6X70AH SCREW DIN0912-M 6X70
-
580912060404 AH SCREW DIN0912-M 6X40AH SCREW DIN0912-M 6X40
-
5956509064100 SELF LOCKING NUT M6 10.9SELF LOCKING NUT M6 10.9
-
600137060000 SPRING WASHER DIN0137-B 6SPRING WASHER DIN0137-B 6
