MASK W/ FENDERS для Ktm 50 Mini Adventure AC - 2003 года выпуска
-
№АртикулНазвание
-
14510801300004 REAR PARTREAR PART
-
245106015000 AIR FILTER 134X96X15 MMAIR FILTER 134X96X15 MM
-
345106012000 FILTER COVERFILTER COVER
-
545108013050 BUSH F. REAR P.BUSH F. REAR P.
-
845007040050 THRUST BEARING QUICK RELEASETHRUST BEARING QUICK RELEASE
-
100981350163 SHEET MET.KR.DIN7981- 3,5X16SHEET MET.KR.DIN7981- 3,5X16
-
174510800700004 NUMBER PLATENUMBER PLATE
-
180015060103 HH COLLAR SCREW M 6X10 WS=8HH COLLAR SCREW M 6X10 WS=8
-
194510801000004 FENDER FRONTFENDER FRONT
-
200014060103 HH COLLAR SCREW M6X10 WS=8HH COLLAR SCREW M6X10 WS=8
-
2145106026000 CARBUR. CONNEC. BOOTCARBUR. CONNEC. BOOT
-
2810001120000 CLAMP 25-40 SGT 4CLAMP 25-40 SGT 4
-
3245106010000 SPLASH PROTECTORSPLASH PROTECTOR
-
3344011076305 CABLE TIE 300/4,8MM BLACKCABLE TIE 300/4,8MM BLACK
-
3445029099000 TOOL SET 50 MINI,TOOL SET 50 MINI,
-
350015060163 HH COLLAR SCREW M 6X16 WS=8HH COLLAR SCREW M 6X16 WS=8
-
3672210079000 BUCKETBUCKET
Все узлы модели:
- ACCESSORIES
- CARBURETOR DELLORTO
- CLUTCH
- CRANKSHAFT PISTON
- CYLINDER W/ CYLINDER HEAD
- DECAL
- ENGINE CASE
- EXHAUST SYSTEM
- FRAME W/ SIDE STAND
- FRESH OIL LUBRICATION
- FRONT AND REAR WHEEL
- FRONT FORK
- HANDLEBAR W/ CONTROLS
- IGNITION SYSTEM
- KICKSTARTER
- • MASK W/ FENDERS
- SPECIAL TOOLS
- SWINGARM W/ SHOCK ABSORBERS
- TANK - SEAT - COVER
- TRANSMISSION
