WIRING HARNESS для Ktm 640 SUPERMOTO - 2005 года выпуска
-
№АртикулНазвание
-
158611075000 WIRING HARNESSWIRING HARNESS
-
258611083000 SUPPORT BRACKET L/SSUPPORT BRACKET L/S
-
349007439000 CLAMP RSGU 15/12CLAMP RSGU 15/12
-
40912050083 AH SCREW DIN 912 M 5X8AH SCREW DIN 912 M 5X8
-
558411057000 STARTER RELAYSTARTER RELAY
-
658411096100 DIODEDIODE
-
758011109110 FUSE 10 AFUSE 10 A
-
80981480133 SHEET MET.SCR.DIN7981- 4,8X13SHEET MET.SCR.DIN7981- 4,8X13
-
90016050121 SCREWSCREW
-
1058011109120 FUSE 20 AFUSE 20 A
-
1145001070000 BRAKE CABLE CLAMP RSGU 9/12BRAKE CABLE CLAMP RSGU 9/12
-
120797050003 TOOTH LOCK WASH. DIN6797-J 5,3TOOTH LOCK WASH. DIN6797-J 5,3
-
1450311060100 DC HORN L.E.B.DC HORN L.E.B.
-
150014060153 HH COLLAR SCREW M 6X15 WS=8HH COLLAR SCREW M 6X15 WS=8
-
1654603048100 RANGE CHANGE METAL NUT M6RANGE CHANGE METAL NUT M6
-
1758411034100 VOLT.REGULATOR-RECTIFIER 12VVOLT.REGULATOR-RECTIFIER 12V
-
1856509064100 SELF LOCKING NUT M6 10.9SELF LOCKING NUT M6 10.9
-
1958611183000 SUPPORT BRACKET R/SSUPPORT BRACKET R/S
-
2158611055000 BRACKET REGULATORBRACKET REGULATOR
-
2458411050000 BRAKE LIGHT SWITCH FRONTBRAKE LIGHT SWITCH FRONT
-
2558411049100 CLUTCH SWITCHCLUTCH SWITCH
-
2650311051100 BRAKE LIGHT SWITCH REARBRAKE LIGHT SWITCH REAR
-
2744611207200 FLASHER UNITFLASHER UNIT
-
2844011076100 CABLE TIE 100/2,5MM BLACKCABLE TIE 100/2,5MM BLACK
-
2844011076200 CABLE TIE 200/3,6MM BLACKCABLE TIE 200/3,6MM BLACK
-
2844011076305 CABLE TIE 300/4,8MM BLACKCABLE TIE 300/4,8MM BLACK
-
2958611076000 WIRING HARNESS REARWIRING HARNESS REAR
-
3058611059000 STARTERCABLE L=810MMSTARTERCABLE L=810MM
-
3158611059050 BATTERY CABLE L=140MMBATTERY CABLE L=140MM
-
3558411053100 BATTERY 12V 8,6AHBATTERY 12V 8,6AH
-
3758611097000 GROUND CABLE L=80MMGROUND CABLE L=80MM
-
380015060103 HH COLLAR SCREW M 6X10 WS=8HH COLLAR SCREW M 6X10 WS=8
-
3958411098100 CONTACT WASHER M6 VSV-K6CONTACT WASHER M6 VSV-K6
-
400015060123 HH COLLAR SCREW M 6X12 WS=8HH COLLAR SCREW M 6X12 WS=8
-
4158411045000 SIDE STAND SWITCH CPL.SIDE STAND SWITCH CPL.
-
4258411070100 HEAD LIGHT SWITCH ADHEAD LIGHT SWITCH AD
-
4358411074200 START-STOP SWITCH ADSTART-STOP SWITCH AD
-
5450303018000 RUBBERRUBBER
-
5658611058050 BRACKET STARTER RELAYBRACKET STARTER RELAY
-
5858211058000 STARTER RELAY 12VSTARTER RELAY 12V
-
730985060003 SELF LOCK. NUT DIN0985-M 6SELF LOCK. NUT DIN0985-M 6
-
8458611087050 BRACKET FUSE BOXBRACKET FUSE BOX
-
8558611059060 TERMINAL POST COVERTERMINAL POST COVER
-
880902060083 AH OVAL SCREW ISO 7380 M 6X8AH OVAL SCREW ISO 7380 M 6X8
