REED VALVE CASE для Ktm 200 XC - 2006 года выпуска
-
№АртикулНазвание
-
4852330051144 REED VALVE ASSY CPL.REED VALVE ASSY CPL.
-
5454630053000 STOP PLATE TOPSTOP PLATE TOP
-
550084040063 CYL.HEAD SCREW DIN0084-M 4X 6ACYL.HEAD SCREW DIN0084-M 4X 6A
-
5654230056000 PAPER STRIPPAPER STRIP
-
580137060003 SPRING WASHER DIN0137-B 6SPRING WASHER DIN0137-B 6
-
590015060303 HH COLLAR SCREW M 6X30 WS=8HH COLLAR SCREW M 6X30 WS=8
-
6054330061000 CLAMP 52/12 GEMICLAMP 52/12 GEMI
-
6154730052040 REED VALVE CARBON 0,4MMREED VALVE CARBON 0,4MM
-
6750330054100 REED VALVE INSERTREED VALVE INSERT
-
6850330050200 INTAKE FLANGEINTAKE FLANGE
-
6954630098000 REED VALVE PLATE 6MMREED VALVE PLATE 6MM
-
7050330098050 GASKET REED V.PLATE V-FORCEGASKET REED V.PLATE V-FORCE
