BRAKE CALIPER FRONT для Ktm 50 SX Senior LC - 2006 года выпуска
-
№АртикулНазвание
-
245113025000 HOLLOW SCREW M6X34HOLLOW SCREW M6X34
-
345113125000 AH SCREW+CIRCLIPAH SCREW+CIRCLIP
-
40799025000 TAB WASHER DIN6799 RS2,5TAB WASHER DIN6799 RS2,5
-
545113012100 BRAKE HOSE FR.BRAKE HOSE FR.
-
60770080019 O-RING 8,00X1,00 EPDMO-RING 8,00X1,00 EPDM
-
845113015000 BRAKE CALIPER CPL.FR.BRAKE CALIPER CPL.FR.
-
945113030000 BRAKE PAD SETBRAKE PAD SET
-
1545113019000 REP.KIT SEAL RINGREP.KIT SEAL RING
-
160015080403 HH COLLAR SCREW M 8X40 WS=10HH COLLAR SCREW M 8X40 WS=10
-
170015080253 HH COLLAR SCREW M 8X25 WS=10HH COLLAR SCREW M 8X25 WS=10
-
180125080003 WASHER DIN0125-A 8,4WASHER DIN0125-A 8,4
-
1945113018000 RETAINING SPRINGRETAINING SPRING
-
200912050203 AH SCREW DIN0912-M 5X20AH SCREW DIN0912-M 5X20
-
2145113020000 BREATHER SCREWBREATHER SCREW
-
5045119050000 BLEEDER INJECTION-SET 0-65BLEEDER INJECTION-SET 0-65
