MAINFOLD для Ktm 640 LC4 ADVENTURE - 2006 года выпуска
-
№АртикулНазвание
-
158405008500 EXHAUST PIPE R/SEXHAUST PIPE R/S
-
258405007400 EXHAUST PIPE L/SEXHAUST PIPE L/S
-
358405058100 COLLECTOR CLAMP D=41MMCOLLECTOR CLAMP D=41MM
-
458405005100 GRAPHIT RING 34X39X20MMGRAPHIT RING 34X39X20MM
-
550305016000 TEN.SPRING L=62MM EY.MOVEABLETEN.SPRING L=62MM EY.MOVEABLE
-
6*5830506504430 BRACKET-PRE SILENCER CPL.BLACKBRACKET-PRE SILENCER CPL.BLACK
-
754305068100 DAMP. COMPONENT SILICONE GREYDAMP. COMPONENT SILICONE GREY
-
80738060181 COU.SUNK SCR. AH ISO7380 M6X18COU.SUNK SCR. AH ISO7380 M6X18
-
90015080353 HH COLLAR SCREW M 8X35HH COLLAR SCREW M 8X35
-
1051005067000 INSOLATE WASHER 8,5X28X3INSOLATE WASHER 8,5X28X3
-
1154603048000 RANGE CHANGE METAL NUT M8RANGE CHANGE METAL NUT M8
