FRONT WHEEL для Ktm 85 SX 17/14 - 2007 года выпуска
-
№АртикулНазвание
-
147009001244 FRONT WHEEL ETFRONT WHEEL ET
-
104700901004491 FRONT WHEEL HUB CPL.FRONT WHEEL HUB CPL.
-
1147009011000 BEARING SPACER TUBEBEARING SPACER TUBE
-
1247009012000 SPACER BUSHINGSPACER BUSHING
-
130760253572 SEAL SHAFT RING 25X35X7 BSLSEAL SHAFT RING 25X35X7 BSL
-
140625060037 GR.BALL BEAR. 6003-2RSH/C3HMTFGR.BALL BEAR. 6003-2RSH/C3HMTF
-
5559009062013 SPECIAL SCREW M6X13 WS=8 10.9SPECIAL SCREW M6X13 WS=8 10.9
-
6047009060000 BRAKE DISC FRONT D=220MMBRAKE DISC FRONT D=220MM
-
7047009070000 RIM FRONT AL4 17X1,40-32RIM FRONT AL4 17X1,40-32
-
7247009072186 SPOKE FRONT 17" 4/3,5/4-186SPOKE FRONT 17" 4/3,5/4-186
-
7350309072000 SPOKE NIPPLE M4,5X0,75 8X21SPOKE NIPPLE M4,5X0,75 8X21
-
7447009073000 RIM BANDRIM BAND
-
8147009081000 AXLE FRONTAXLE FRONT
-
8349032011000 HH COLLAR SCREW M10X20 WS=17HH COLLAR SCREW M10X20 WS=17
-
8655009086000 PLUG SFL13PLUG SFL13
-
8955003135000 PLUG FOR RIMPLUG FOR RIM
-
9050310090050 NUT FOR WHEEL HOLDERNUT FOR WHEEL HOLDER
