WATER PUMP для Ktm 450 SX-F FACTORY - 2012 года выпуска
-
№АртикулНазвание
-
561230045000 CAP NUT M6 STAINLESS STEELCAP NUT M6 STAINLESS STEEL
-
681235055020 WATER PUMP ROTORWATER PUMP ROTOR
-
781235055110 DISC WATER PUMPDISC WATER PUMP
-
80760123073 SHAFT SEAL RING 12X30X7 PTFESHAFT SEAL RING 12X30X7 PTFE
-
1178135053000 WATER-PUMP GASKETWATER-PUMP GASKET
-
1278135052000 WATER PUMP COVER CPL.WATER PUMP COVER CPL.
-
130025060256 HH COLLAR SCREW M6X25 TX30HH COLLAR SCREW M6X25 TX30
-
140025060656 HH COLLAR SCREW M6X65 TX30HH COLLAR SCREW M6X65 TX30
-
150603061001 CU-SEAL RING DIN7603 -6X10X1CU-SEAL RING DIN7603 -6X10X1
