CYLINDER HEAD для Ktm 200 DUKE WHITE - 2014 года выпуска
-
№АртикулНазвание
-
190636020033 CYLINDER HEAD CPL.CYLINDER HEAD CPL.
-
290136052000 VALVE COVERVALVE COVER
-
390136053000 VALVE COVER GASKETVALVE COVER GASKET
-
490630036000 CYLINDER HEAD GASKETCYLINDER HEAD GASKET
-
590136025000 VALVE GUIDEVALVE GUIDE
-
690130064000 OIL JETOIL JET
-
7J025060402 HH-COLLAR SCREW M6X40 WS10HH-COLLAR SCREW M6X40 WS10
-
8J025060356 HH-COLLAR SCREW M6X35 WS8HH-COLLAR SCREW M6X35 WS8
-
990130024000 PIN DOWEL 8X6,4X14MMPIN DOWEL 8X6,4X14MM
-
1090136020005 COLLAR SCREW M6COLLAR SCREW M6
-
1190136020003 HH COLLAR SCREW 10X147,5HH COLLAR SCREW 10X147,5
-
1290130080000 WASHER 11,2X20X2WASHER 11,2X20X2
-
1390136020001 STUD M8STUD M8
-
1490136038000 FLANGED NUT M8 H7,5 WS12FLANGED NUT M8 H7,5 WS12
-
1590135047000 TEMPERATURE SENSORTEMPERATURE SENSOR
-
1690135047001 O-RINGO-RING
-
1790138091000 OIL PRESSURE SENSOROIL PRESSURE SENSOR
-
1890138091001 O-RINGO-RING
-
1990136052020 VALVE COVER SCREWVALVE COVER SCREW
-
2090136052010 DECOUPLING ELEMENTDECOUPLING ELEMENT
-
21J770023019 O-RING 23,7X1,9O-RING 23,7X1,9
