SHIFTING MECHANISM для Ktm 690 DUKE ABS BLACK - 2015 года выпуска
-
№АртикулНазвание
-
175034002100 SHIFT FORK F . SLIDINGGEAR 5SHIFT FORK F . SLIDINGGEAR 5
-
275034001100 SHIFT FORK F . SLIDINGG. 3/4SHIFT FORK F . SLIDINGG. 3/4
-
375034003100 SHIFT FORK F . SLIDING GEAR 6SHIFT FORK F . SLIDING GEAR 6
-
40402061480 NEEDLE ROLLER DIN5402 6X14,8NEEDLE ROLLER DIN5402 6X14,8
-
575034019000 SHIFT RAILSHIFT RAIL
-
675034005133 SHIFT SHAFT ASSYSHIFT SHAFT ASSY
-
756534013100 TENSIONING SPRING 0,8MMTENSIONING SPRING 0,8MM
-
854634120000 SPRING GUIDESPRING GUIDE
-
954834014000 RETURN SPRINGRETURN SPRING
-
1075034050000 STOP DISK 14X30X1,5 STEELSTOP DISK 14X30X1,5 STEEL
-
1154632095000 NEEDLE BEAR.HK 1412 14X20X12NEEDLE BEAR.HK 1412 14X20X12
-
120760142461 SHAFT SEAL RING 14X24X6B VITONSHAFT SEAL RING 14X24X6B VITON
-
200024060206 HH COLLAR SCREW M6X20 TX30HH COLLAR SCREW M6X20 TX30
-
2175034024044 LOCKING LEVER CPL.LOCKING LEVER CPL.
-
2275034052000 SLEEVE FOR LOCKING LEVERSLEEVE FOR LOCKING LEVER
-
2360034023000 ARRESTING LEVER SPRINGARRESTING LEVER SPRING
-
240912060303 AH SCREW DIN0912-M 6X30AH SCREW DIN0912-M 6X30
-
2575034015000 SHIFT DRUM LOCATING CPL.SHIFT DRUM LOCATING CPL.
-
260625618050 BALL BEARING 61805 C3BALL BEARING 61805 C3
-
2776034112044 SHIFTING DRUM CPL.SHIFTING DRUM CPL.
-
280618354212 NEEDLE BEAR HK3512 35X42X12NEEDLE BEAR HK3512 35X42X12
-
3475034006000 SPACERSPACER
-
3675034007000 SPRING FOR OPERATING SHAFTSPRING FOR OPERATING SHAFT
-
38073800501001 FLAT HEAD SCREW ISO 7380 M5X10FLAT HEAD SCREW ISO 7380 M5X10
-
3907700240251 O-RING 24X2,5 VITONO-RING 24X2,5 VITON
-
4060211023100 GEAR-POSITION SENSORGEAR-POSITION SENSOR
-
430984050163S CYL. SCREW DIN6912 M5X16 8.8CYL. SCREW DIN6912 M5X16 8.8
-
440125050003 WASHER DIN0125-A 5,3WASHER DIN0125-A 5,3
