TANK - SEAR - COVER для Ktm 85 SXS 17/14 - 2015 года выпуска
-
№АртикулНазвание
-
14710805400028A SPOILER SET W/ DECALSPOILER SET W/ DECAL
-
24710701314430 FUEL TANK CPL.FUEL TANK CPL.
-
37770700814404 TANK PLUG CPL.TANK PLUG CPL.
-
40017060253 EJOT PT SCREW K60X25-Z SW6EJOT PT SCREW K60X25-Z SW6
-
550307005000 GAS COCK MIKUNI ON/OFFGAS COCK MIKUNI ON/OFF
-
60770130023 O-RING 13,00X2,30O-RING 13,00X2,30
-
747107040000 SEAT CPL.SEAT CPL.
-
847107040050 SEATCOVERSEATCOVER
-
950332095200 TUBE RUBBER 6X9 DVOH 200MMTUBE RUBBER 6X9 DVOH 200MM
-
1450307014000 TANK ROLLER 12X26X12TANK ROLLER 12X26X12
-
1577307026000 TANK BUSHINGTANK BUSHING
-
1745031005000 YDNAC-C LAMP FUEL HOSE (8MM)YDNAC-C LAMP FUEL HOSE (8MM)
-
1878007000270 PVC-HOSE 5,6X10X270M MPVC-HOSE 5,6X10X270M M
-
1912011016000 WASHER 6 X 12 X 3WASHER 6 X 12 X 3
-
200026060136 COLLAR SCREW M6X13 ISA30COLLAR SCREW M6X13 ISA30
-
210024060273 COLLAR SCREW M6X27 TXCOLLAR SCREW M6X27 TX
-
220017060206 SCREW F . PLASTIC K60X20AL SW6SCREW F . PLASTIC K60X20AL SW6
-
240021060003 WASHER DIN9021-A 6,4WASHER DIN9021-A 6,4
-
250024060156 HH COLLAR SCREW M6X15 TX30HH COLLAR SCREW M6X15 TX30
