TIMING DRIVE для Ktm RC 390 USA - 2015 года выпуска
-
№АртикулНазвание
-
190236009033 CAMSHAFT INTAKE CPL.CAMSHAFT INTAKE CPL.
-
290236010133 CAMSHAFT EXHAUST CPL.CAMSHAFT EXHAUST CPL.
-
390236037000 SCREW CAMSHAFT SPROCKETSCREW CAMSHAFT SPROCKET
-
490236009003 SPROCKET CAMSHAFTSPROCKET CAMSHAFT
-
1190236018000 CHAIN GUIDE TOPCHAIN GUIDE TOP
-
12J025060401 HH COLLAR SCREW M6X40HH COLLAR SCREW M6X40
-
1390236001000 TIMING CHAIN GUIDETIMING CHAIN GUIDE
-
1490236013000 TIMING CHAINTIMING CHAIN
-
1590236002000 TENSIONER RAIL CPL.TENSIONER RAIL CPL.
-
1690236002004 SCREW TENSIONER RAILSCREW TENSIONER RAIL
-
1790136003003 GASKET CHAIN ADJUSTERGASKET CHAIN ADJUSTER
-
18J770010015 O-RING 10,15X1,5O-RING 10,15X1,5
-
1990236003044 CHAIN ADJUSTERCHAIN ADJUSTER
-
20J025060206 HH COLLAR SCREW M6X20 SW10HH COLLAR SCREW M6X20 SW10
-
2190136003002 SPECIAL SCREW 6X6SPECIAL SCREW 6X6
