TRANSMISSION - COUNTERSHAFT для Ktm 150 SX - 2017 года выпуска

№

Артикул

Название
1

50433010000 DRIVEN SHAFT CPL.

DRIVEN SHAFT CPL.

36 340 ₽
2

0405222611 NEEDLE BEAR.K 22X26X10 DIVIDED

NEEDLE BEAR.K 22X26X10 DIVIDED

3 130 ₽
3

50433012000 IDLER GEAR, 2ND GEAR, 30T

IDLER GEAR, 2ND GEAR, 30T

18 840 ₽
4

54833044000 STOP DISC 25X31X1,5

STOP DISC 25X31X1,5

1 030 ₽
5

0417024000 CIRCLIP WS24

CIRCLIP WS24

320 ₽
6

50433016000 SLIDING GEAR, 6TH GEAR, 24T

SLIDING GEAR, 6TH GEAR, 24T

22 110 ₽
7

54833043000 STOP DISC 25X0,8X30X30X7H

STOP DISC 25X0,8X30X30X7H

1 200 ₽
8

50433013000 IDLER GEAR, 3RD GEAR, 28T

IDLER GEAR, 3RD GEAR, 28T

75 320 ₽
9

50433014000 IDLER GEAR, 4TH GEAR, 28T

IDLER GEAR, 4TH GEAR, 28T

75 320 ₽
10

50433015000 SLIDING GEAR, 5TH GEAR, 23T

SLIDING GEAR, 5TH GEAR, 23T

28 240 ₽
11

54833080000 STOP DISC 20,2X30X1

STOP DISC 20,2X30X1

640 ₽
12

50433011000 IDLER GEAR, 1ST GEAR, 32T

IDLER GEAR, 1ST GEAR, 32T

20 330 ₽
13

0405202410 NEEDLE BEARING K20X24X10

NEEDLE BEARING K20X24X10

3 070 ₽
14

56033030000 STOP DISC 17,2X30X1

STOP DISC 17,2X30X1

970 ₽
15

0625160031 GROOVED BALL B. 16003 C4 J1

GROOVED BALL B. 16003 C4 J1

5 520 ₽
16

0625062054 BALL BEARING 6205 C3 NTN

BALL BEARING 6205 C3 NTN

5 550 ₽
17

0760324571 SHAFT SEAL RING 32X45X7 BSLNBR

SHAFT SEAL RING 32X45X7 BSLNBR

1 140 ₽
18

0770230020 O-RING 23,00X2,00 NBR70

O-RING 23,00X2,00 NBR70

290 ₽
19

50433030000 SP ACER BUSHING 12,4 MM

SP ACER BUSHING 12,4 MM

5 120 ₽
20

79233029013 SPROCKET 13T

SPROCKET 13T

8 110 ₽
21

0471250200 CIRCLIP DIN0471 - 25X2

CIRCLIP DIN0471 - 25X2

180 ₽
99

00050000949 COUNTER SHAFT REP . KIT 125 SX

COUNTER SHAFT REP . KIT 125 SX

9 140 ₽
