FRAME для Ktm 250 SX - 2017 года выпуска
-
№АртикулНазвание
-
15540300100033 FRAME "554Q3" BLACKFRAME "554Q3" BLACK
-
279003002000 SUBFRAME 2016SUBFRAME 2016
-
377303139000 BLIND RIVET NUT EM6-60LF/HXBLIND RIVET NUT EM6-60LF/HX
-
40019080206S FLAT HEAD SCREW M. ISA45 M8X20FLAT HEAD SCREW M. ISA45 M8X20
-
579003003000 SPECIAL SCREW M8X18 TORX45 SSSPECIAL SCREW M8X18 TORX45 SS
-
655403013000 ENGINE BRACE LEFT 17ENGINE BRACE LEFT 17
-
755403014000 ENGINE BRACE RIGHT 17ENGINE BRACE RIGHT 17
-
80035080156S AH-COLLAR SCREW M8X15 TORX45AH-COLLAR SCREW M8X15 TORX45
-
979007012000 TANK REST RUBBERTANK REST RUBBER
-
1058111076000 CABLE SUPPORT KHS NR.150-47610CABLE SUPPORT KHS NR.150-47610
-
110025080166S HH COLLAR SCREW M8X16HH COLLAR SCREW M8X16
-
1250335030001 PVC-HOSE 6X9PVC-HOSE 6X9
-
1350303089000 ANGLE PIECEANGLE PIECE
-
1454310086100 SELF LOCKING NUT M10 CU WS=14SELF LOCKING NUT M10 CU WS=14
-
1577203014000 ENGINE BRAC.SCR. M10X115ENGINE BRAC.SCR. M10X115
-
180025080306 HH COLLAR SCREW M8X30HH COLLAR SCREW M8X30
-
190025060406 HH COLLAR SCREW M6X40HH COLLAR SCREW M6X40
-
200125060003 WASHER DIN0125-A 6,4WASHER DIN0125-A 6,4
-
2179003040000 FOOTREST L/SFOOTREST L/S
-
2279003041000 FOOTREST R/SFOOTREST R/S
-
230125100003 WASHER DIN0125-A10,5WASHER DIN0125-A10,5
-
2479003044000 FOOTREST SPRING R/SFOOTREST SPRING R/S
-
2554803044000 PIN FOR FOOT PED 51.5X9.8 MMPIN FOR FOOT PED 51.5X9.8 MM
-
2679003045000 FOOTREST SPRING L/SFOOTREST SPRING L/S
-
270094032253 PIN DIN0094-3,2X25 STEELPIN DIN0094-3,2X25 STEEL
-
2879003040033 FOOT PEGS SET CPL. 2016FOOT PEGS SET CPL. 2016
-
290014050123 HH COLLAR SCREW M 5X12HH COLLAR SCREW M 5X12
-
3054803092060 BUSH F. FRAME PROTECTIONBUSH F. FRAME PROTECTION
-
3144011076305 CABLE TIE 300/4,8MM BLACKCABLE TIE 300/4,8MM BLACK
-
3244011076140 CABLE TIE 140/2,5MM BLACKCABLE TIE 140/2,5MM BLACK
-
337900309400033 FRAME PROTECTION SET BLACKFRAME PROTECTION SET BLACK
-
3479003002080 BLIND RIVET NUT M6 KNURLEDBLIND RIVET NUT M6 KNURLED
-
9879003053010 CHAIN SLIDING KIT BELOW CPL.CHAIN SLIDING KIT BELOW CPL.
-
9955403096010 SPROCKET COVER KITSPROCKET COVER KIT
