CAMSHAFT W/ VALVE ASSY. для Polaris MAGNUM 330 2X4 (A03CB32AA) - 2003 года выпуска
-
№АртикулНазвание
-
13084911 SCREW, ADJUSTSCREW, ADJUST
-
23084912 NUTNUT
-
33084910 ROCKERARM ASSY., INTAKE (INCL. 1, 2)ROCKERARM ASSY., INTAKE (INCL. 1, 2)
-
43087053 SHAFT, ROCKERSHAFT, ROCKER
-
53085836 WASHER, WAVEWASHER, WAVE
-
63084908 COLLET, VALVECOLLET, VALVE
-
73087203 RETAINER, VALVE SPRINGRETAINER, VALVE SPRING
-
83087248 SPRING, VALVESPRING, VALVE
-
93086439 LEVER, RELEASE ASSY.LEVER, RELEASE ASSY.
-
103086804 SPRING, RETURNSPRING, RETURN
-
113087247 CAMSHAFT ASSY. (INCL. 9, 10, 12)CAMSHAFT ASSY. (INCL. 9, 10, 12)
-
123087254 PIN, DOWELPIN, DOWEL
-
133085778 VALVE, INTAKEVALVE, INTAKE
-
143086441 VALVE, EXHAUSTVALVE, EXHAUST
-
153086445 GUIDE, CHAINGUIDE, CHAIN
-
163086444 CHAIN, TIMINGCHAIN, TIMING
-
173086448 GASKET, TENSIONERGASKET, TENSIONER
-
183086493 TENSIONER, ASSY.TENSIONER, ASSY.
-
193087132 PINPIN
-
203087131 SPRING, TENSIONERSPRING, TENSIONER
-
213087130 GASKET, PLUGGASKET, PLUG
-
223087129 PLUGPLUG
-
233083361 BOLT, FLANGEBOLT, FLANGE
-
243086443 SPROCKET 2SPROCKET 2
-
253087249 WASHERWASHER
-
263086449 BOLT, FLANGEBOLT, FLANGE
-
273086446 LEVER ASSY.LEVER ASSY.
-
283084924 BOLT PIVOT LEVER ASSY.BOLT PIVOT LEVER ASSY.
