FUEL TANK W/HOSES для Polaris SPORTSMAN 90 (A09FA09AB) (RED) - 2009 года выпуска
-
№АртикулНазвание
-
10453691 CAP-FUEL,OUTLAWCAP-FUEL,OUTLAW
-
20452641 GASKET-CAPGASKET-CAP
-
30453944 CLAMPCLAMP
-
40454031 HOSE-VENT,FUEL TANKHOSE-VENT,FUEL TANK
-
50453720 SCREWSCREW
-
60453719 WASHERWASHER
-
70453716 SPACER-TANK,FUELSPACER-TANK,FUEL
-
80453693 CLAMP-HOSECLAMP-HOSE
-
90454121 HOSEHOSE
-
110450054 CLIPCLIP
-
120454122 HOSEHOSE
-
140454026-130 HOSE-FUEL,NON-PERM,130MMHOSE-FUEL,NON-PERM,130MM
-
150453695 FILTER-FUEL 65 MICRONFILTER-FUEL 65 MICRON
-
160454026-105 HOSE-FUEL,NON-PERM,105MMHOSE-FUEL,NON-PERM,105MM
-
170450996 MANUAL FUEL CUP,ASM.-(FUEL VALVE)MANUAL FUEL CUP,ASM.-(FUEL VALVE)
-
180450866 BOLT-PANBOLT-PAN
-
190453715 KNOB-SHUT-OFF,FUELKNOB-SHUT-OFF,FUEL
-
200453717 BOLTBOLT
-
210450340 BOLT-HEXBOLT-HEX
-
220453696 ADHESIVE-ELE WIREADHESIVE-ELE WIRE
-
230453718 ASM-TANK,FUEL,SPORTSMANASM-TANK,FUEL,SPORTSMAN
