GEARCASE - FRONT для Polaris SPORTSMAN TOURING 570 EFI MD SAGEBRUSH GREEN [A15SDA57HA] - 2015 года выпуска
-
№АртикулНазвание
-
11333393 ASM., GEARCASE, FRONT, 12 POCKET (INCL. ALL)ASM., GEARCASE, FRONT, 12 POCKET (INCL. ALL)
-
23235162 ASM., COVER, OUTPUTASM., COVER, OUTPUT
-
33234936 KIT, OUTPUT HUB (INCL. HUB ASM. FEMALE, HUB ASM. MALE)KIT, OUTPUT HUB (INCL. HUB ASM. FEMALE, HUB ASM. MALE)
-
43235469 KIT, BOLT (INCL. SCREWS)KIT, BOLT (INCL. SCREWS)
-
53235470 KIT, SEAL REPAIR (INCL. ALL SEALS)KIT, SEAL REPAIR (INCL. ALL SEALS)
-
63235485 PLATE, ARMATUREPLATE, ARMATURE
-
93235638 KIT, GEAR CLUTCH HOUSING, PINIONKIT, GEAR CLUTCH HOUSING, PINION
-
103234390 BEARINGBEARING
-
113235624 KIT, ROLLER (INCL. COMPLETE SET OF ROLLERS)KIT, ROLLER (INCL. COMPLETE SET OF ROLLERS)
-
123235625 ASM., ROLL CAGE (INCL. CAGE AND COMPLETE SET OF CLIPS)ASM., ROLL CAGE (INCL. CAGE AND COMPLETE SET OF CLIPS)
-
133235728 ASM., GEARCASE (INCL. GEARCASE, BUSHING, GARLOCK BEARING, FILL PLUG, VENT TUBE, OIL SEAL)ASM., GEARCASE (INCL. GEARCASE, BUSHING, GARLOCK BEARING, FILL PLUG, VENT TUBE, OIL SEAL)
-
143234412 ASM., DRAIN PLUG, MAGNETICASM., DRAIN PLUG, MAGNETIC
-
153235712 KIT, SPRING (INCL. SPRING RETAINER, TORSION SPRING)KIT, SPRING (INCL. SPRING RETAINER, TORSION SPRING)
-
163234414 PLUG, OIL FILLPLUG, OIL FILL
