A-ARMS - FRONT для Polaris SPORTSMAN® Touring XP 1000 (BLACK PEARL) [A16SYE95AK] - 2016 года выпуска
-
№АртикулНазвание
-
11019808-385 ARM, CONTROL, UPPER, FRONT, LH, CLOUD SILVERARM, CONTROL, UPPER, FRONT, LH, CLOUD SILVER
-
11019809-385 ARM, CONTROL, UPPER, FRONT, RH, CLOUD SILVERARM, CONTROL, UPPER, FRONT, RH, CLOUD SILVER
-
21019810-385 ARM, CONTROL, LOWER, FRONT, CLOUD SILVER, LHARM, CONTROL, LOWER, FRONT, CLOUD SILVER, LH
-
21019811-385 ARM, CONTROL, LOWER, FRONT, CLOUD SILVER, RHARM, CONTROL, LOWER, FRONT, CLOUD SILVER, RH
-
37710533 RING, RETAININGRING, RETAINING
-
47061220 JOINT, BALLJOINT, BALL
-
57547405 NUT, NYLOKNUT, NYLOK
-
67519212 SCREW, FLANGESCREW, FLANGE
-
77080433 FITTING, LUBRICATINGFITTING, LUBRICATING
-
85439874 BUSHINGBUSHING
-
95137346 SHAFT, A-ARMSHAFT, A-ARM
-
107518466 BOLT, FLANGEBOLT, FLANGE
-
117547313 NUT, FLANGENUT, FLANGE
-
125436657-070 SHIELD, CV, FRONT, LH, CLOUD SILVERSHIELD, CV, FRONT, LH, CLOUD SILVER
-
125436658-070 SHIELD, CV, FRONT, RH, CLOUD SILVERSHIELD, CV, FRONT, RH, CLOUD SILVER
-
137518529 SCREWSCREW
-
147556557 WASHERWASHER
Все узлы модели:
- • A-ARMS - FRONT
- AIR INTAKE SYSTEM
- BATTERY
- BRAKE - FRONT CALIPER
- BRAKE - FRONT MASTER CYLINDER
- BRAKE - PEDAL W/MASTER CYLINDER
- BRAKE - REAR CALIPER
- BRAKE LINES
- BUMPER - FRONT
- CAMSHAFT W/ CHAIN
- CARGO BOX - FRONT
- CLUTCH - PRIMARY
- CLUTCH - SECONDARY
- CLUTCH COVER
- COOLING BYPASS
- COOLING SYSTEM
- COOLING SYSTEM - WATER PUMP
- CRANKCASE
- CRANKSHAFT W/ CYLINDER
- CYLINDER HEAD - CAM - VALVES
- DECALS
- DRIVE COUPLER
- DRIVESHAFT - FRONT
- DRIVESHAFT - REAR
- ELECTRICAL - BULBS
- ELECTRICAL - GPS HARNESS
- ELECTRICAL COMPONENTS
- ENGINE - LONG BLOCK
- EXHAUST SYSTEM
- FENDER - FRONT W/ SIDE PANELS
- FRAME
- FRONT BRUSHGUARD
- FUEL TANK
- GAUGES AND INDICATOR
- GEAR SELECTOR
- GEARCASE
- GEARCASE - FRONT - MOUNTING
- GEARCASE - INTERNAL COMPONENTS - FRONT
- GEARCASE - REAR - MOUNTING
- HANDGUARDS
- HANDLEBAR - CONTROL ASSY.
- HEADLIGHT
- HEADLIGHT POD
- IGNITION SYSTEM
- MAIN FRAME AND SKID PLATE
- MANUAL - OWNERS
- MIRRORS AND HAND WARMERS
- MOUNTING - ENGINE W/TRANSMISSION
- OIL PUMP AND OIL FILTER
- RACK - FRONT SUPPORT
- RACK - REAR
- SEAT - OPERATOR
- SEAT - PASSENGER - BOTTOM AND BACK
- SHAFT - BALANCER
- SHOCK ABSORBER - FRONT
- SHOCK ABSORBER - REAR
- SHOCK MOUNTING- FRONT
- SHOCK MOUNTING- REAR
- SKID PLATES
- STARTING MOTOR
- STEERING POST
- SUSPENSION - REAR
- SUSPENSION - TORSION BAR
- TAILLIGHT
- THROTTLE ASSY.
- THROTTLE BODY
- TOOL KIT
- VALVE COVER
- WHEEL - FRONT W/ HUB
- WHEEL - REAR W/ HUB
- WINCH
- WIRE HARNESS
