REAR SHOCK INTERNALS для Polaris RZR XP 4 1000 EPS (WHITE LIGHTNING) [Z17VFE99AW] - 2017 года выпуска
-
№АртикулНазвание
-
17044557 SHOCK, REAR [INCL ALL]SHOCK, REAR [INCL ALL]
-
21800836 2.5IN SPRING NUT (CLEAR)2.5IN SPRING NUT (CLEAR)
-
31800752 RES, PISTON 2.5IN ASMRES, PISTON 2.5IN ASM
-
41800854 2.5IN 9.5L PB RES CAN WR (HARD CLEAR)2.5IN 9.5L PB RES CAN WR (HARD CLEAR)
-
51800632 SS 7/8IN CHROME NEEDLE SHAFT 18.295LSS 7/8IN CHROME NEEDLE SHAFT 18.295L
-
61800657 SPACER 2.037LSPACER 2.037L
-
71800201 1.25 BUMP STOP LG1.25 BUMP STOP LG
-
81800613 O-RING 2-033O-RING 2-033
-
91800508 O-RING 2-327O-RING 2-327
-
101800500 O-RING 2-225O-RING 2-225
-
111800482 RING- RETAIN (SNAP)RING- RETAIN (SNAP)
-
121800638 42567 NY LOCK NUT42567 NY LOCK NUT
-
131800838 BODY, MONOTUBE 2.5 REAR W NEEDLE HARD CLEAR 21.070LBODY, MONOTUBE 2.5 REAR W NEEDLE HARD CLEAR 21.070L
-
141800855 CAP, WIPER,2.5 PRESS FIT 42559 (CLEAR)CAP, WIPER,2.5 PRESS FIT 42559 (CLEAR)
-
151800856 ASM. SEAL HEAD 2.5 X 0.875 PIASM. SEAL HEAD 2.5 X 0.875 PI
-
161800840 NEEDLE, 1PC PRESS INNEEDLE, 1PC PRESS IN
-
171800841 BRIDGE, 2.5 WER ADJUSTER (CLEAR)BRIDGE, 2.5 WER ADJUSTER (CLEAR)
-
181800842 2.5IN CROSSOVER RING/ JAM NUT2.5IN CROSSOVER RING/ JAM NUT
-
191800488 2.5 RES MOUNT2.5 RES MOUNT
-
201800843 #8-32 X 0.5 LOW HEAD SCREW#8-32 X 0.5 LOW HEAD SCREW
-
211800754 SCREW, SHCS 43834 X .5"SCREW, SHCS 43834 X .5"
-
221501007 SPRING CLIPSPRING CLIP
-
231800847 RETAINING RING 2.5RETAINING RING 2.5
-
241800846 2.48 X 0.0625 WIRE RING2.48 X 0.0625 WIRE RING
-
251800095 O-RING 2-112O-RING 2-112
-
261800497 O-RING 2-230O-RING 2-230
-
271800641 WIPER 2.5 SH 0.875 SHAFTWIPER 2.5 SH 0.875 SHAFT
-
281800502 O-RING, 2-134O-RING, 2-134
-
291800486 PISTON ASSEMBLY (.100 BLEED)PISTON ASSEMBLY (.100 BLEED)
-
301800844 ASM. END CAP, 2.5 SCHRAEDERASM. END CAP, 2.5 SCHRAEDER
-
311800555 42629 HEIM SHAFTLOOP (CLEAR)42629 HEIM SHAFTLOOP (CLEAR)
-
321800503 O-RING 2-122O-RING 2-122
-
331800848 VALVE, CHECK ASMVALVE, CHECK ASM
-
341800592 BEARING, SPHR COM9T- 500, 1.093 UTVBEARING, SPHR COM9T- 500, 1.093 UTV
-
351800857 ASM. SS RETENTION NUT (GOLD)ASM. SS RETENTION NUT (GOLD)
