STRUT AND HANGER MOUNTING для Polaris TOURING CRUISER (CALIFORNIA) [V06TB16LA] - 2006 года выпуска
-
№АртикулНазвание
-
15811941 PAD, RUBBERPAD, RUBBER
-
21013951-067 STRUT, LEFT HANDSTRUT, LEFT HAND
-
21013952-067 STRUT, RIGHT HANDSTRUT, RIGHT HAND
-
35133702 BUSHING, FENDER, REAR, SILVERBUSHING, FENDER, REAR, SILVER
-
47518155 SCREWSCREW
-
57517838 SCREWSCREW
-
61013641 ASM., COVER STRUT, LEFT HAND (INCL. CLIPS)ASM., COVER STRUT, LEFT HAND (INCL. CLIPS)
-
61013642 ASM., COVER STRUT, RIGHT HAND (INCL. CLIPS)ASM., COVER STRUT, RIGHT HAND (INCL. CLIPS)
-
67670139 CLIP, STRUTCLIP, STRUT
-
77517887 SCREWSCREW
-
87556164 WASHERWASHER
-
95246681 BRACKET, LUGGAGE RACKBRACKET, LUGGAGE RACK
-
107517888 SCREWSCREW
-
117517951 SCREWSCREW
-
121012963-067 HANGER, REARHANGER, REAR
-
131013164-266 FENDER, REAR (BLACK)FENDER, REAR (BLACK)
-
131013164-508 FENDER, REAR (SEDONA)FENDER, REAR (SEDONA)
-
131013164-509 FENDER, REAR (SPRGRAPH)FENDER, REAR (SPRGRAPH)
-
147547076 NUT, HEXNUT, HEX
-
152874780 KIT, RACKKIT, RACK
