FRAME для Polaris VEGAS 8-BALL [GA36] - 2015 года выпуска
-
№АртикулНазвание
-
11018526-266 FRAME, MAIN, (BLACK)FRAME, MAIN, (BLACK)
-
21016078-266 CRADLE, RIGHT HAND, (BLACK)CRADLE, RIGHT HAND, (BLACK)
-
35137536-266 CRADLE, LEFT HAND, (BLACK)CRADLE, LEFT HAND, (BLACK)
-
47518053 SCREWSCREW
-
51014760-408 PLATE, NUT, ZINC (BLACK)PLATE, NUT, ZINC (BLACK)
-
67556305 WASHER, FLATWASHER, FLAT
