PROPULSION для Polaris Genesis 4-Pass Euro - 2000 года выпуска
-
№АртикулНазвание
-
15411107 SEAL, WATER PIPESEAL, WATER PIPE
-
25411016 SEAL, SIPHON TUBESEAL, SIPHON TUBE
-
35431990 TUBE, SIPHONTUBE, SIPHON
-
47542455 NUT, HEXNUT, HEX
-
55244556 BRACKET, STEERING CABLE NUTBRACKET, STEERING CABLE NUT
-
67555941 WASHER, PUMP STUD SEALWASHER, PUMP STUD SEAL
-
75132355 STUD, MOUNT PUMP (1.38 INT)STUD, MOUNT PUMP (1.38 INT)
-
85433334 PIPE, WATER ENGINE (7.4 INCH)PIPE, WATER ENGINE (7.4 INCH)
-
95410735 O-RINGO-RING
-
103514008 BEARINGBEARING
-
115010294 SPACERSPACER
-
125132088 STATORSTATOR
-
135410817 O-RINGO-RING
-
145410818 O-RINGO-RING
-
155020697 SHAFT, STUBSHAFT, STUB
-
165410819 O-RINGO-RING
-
173610043 SEAL, BEARING STATORSEAL, BEARING STATOR
-
185010295 SPACER, IMPELLERSPACER, IMPELLER
-
195131366 IMPELLER (17-23)IMPELLER (17-23)
-
208450054-100 HOSE, WATERHOSE, WATER
-
217080138 CABLE TIECABLE TIE
-
227522019 SCREWSCREW
-
235630598 BUSHINGBUSHING
-
245131574 HOUSING, PUMP W/RING INT STUDHOUSING, PUMP W/RING INT STUD
-
257555966 WASHERWASHER
-
265811984 SEAL, TAILCONESEAL, TAILCONE
-
275431523 SCREEN, ENGINE INLETSCREEN, ENGINE INLET
-
285432841 WEDGE, PUMP MOLDEDWEDGE, PUMP MOLDED
-
297517654 SCREWSCREW
-
307555835 WASHER, FLATWASHER, FLAT
-
317552610 WASHER, LOCKWASHER, LOCK
-
325130999 NOZZLE, STEERINGNOZZLE, STEERING
-
335431518 BEARING, STEERING NOZZLEBEARING, STEERING NOZZLE
-
345130938 COLLARCOLLAR
-
357515366 BOLTBOLT
-
361350038 NOZZLE ASSY. WEDGENOZZLE ASSY. WEDGE
-
375431519 CONE, PUMPCONE, PUMP
-
387512064 SCREWSCREW
