FUEL TANK для Polaris Genesis FFI 4-Pass Euro - 2000 года выпуска
-
№АртикулНазвание
-
15240134 CLIP, STRAPCLIP, STRAP
-
25243775 HOOK, STRAPHOOK, STRAP
-
37621479 RIVETRIVET
-
45430621 STRAPSTRAP
-
65243776 HOOK, STRAPHOOK, STRAP
-
75410608 STRAP, BATTERY (RUBBER)STRAP, BATTERY (RUBBER)
-
87080442 COUPLING, ENDCOUPLING, END
-
97511873 SCREWSCREW
-
107080710 CHAIN, BEADCHAIN, BEAD
-
117621229 RIVETRIVET
-
122520177 CAP, FUEL RATCHET ASSY.CAP, FUEL RATCHET ASSY.
-
135411305 SEAL, FUEL CAPSEAL, FUEL CAP
-
145433553 INLET, FUELINLET, FUEL
-
155811492 SEAL, FUEL INLETSEAL, FUEL INLET
-
165433621 NUT, INLET FUELNUT, INLET FUEL
-
177080766 CLAMP, HOSECLAMP, HOSE
-
185411546 HOSE, FILL FUELHOSE, FILL FUEL
-
197080451 CLAMP, HOSECLAMP, HOSE
-
205811999 PAD, FUEL TANK (REAR)PAD, FUEL TANK (REAR)
-
215433256 TANK, FUEL (17 GAL)TANK, FUEL (17 GAL)
-
225811901 PAD, TANK FUEL SIDEPAD, TANK FUEL SIDE
-
235811790 PAD, TANK, FUELPAD, TANK, FUEL
-
247555837 WASHER, FLATWASHER, FLAT
-
255411636 GASKETGASKET
-
262410129 PUMP, FUEL ELECTRICPUMP, FUEL ELECTRIC
-
275433259 NUTNUT
