PROPULSION для Polaris PRO 1200 2-Pass Euro - 2000 года выпуска
-
№АртикулНазвание
-
17542455 NUT, HEXNUT, HEX
-
27555966 WASHERWASHER
-
35431990 SIPHON TUBESIPHON TUBE
-
47555866 WASHERWASHER
-
55411016 SEAL, SIPHON TUBESEAL, SIPHON TUBE
-
65411107 SEAL, WATER PIPESEAL, WATER PIPE
-
75432269 PIPE, WATER ENGINEPIPE, WATER ENGINE
-
85410735 O-RINGO-RING
-
95132088 STATORSTATOR
-
105131196 EXTENSION, PUMPEXTENSION, PUMP
-
115010294 SPACERSPACER
-
123514008 BEARINGBEARING
-
133610043 SEAL, BEARING STATORSEAL, BEARING STATOR
-
145010295 SPACER, IMPELLERSPACER, IMPELLER
-
155132202 IMPELLERIMPELLER
-
165411644 SEAL, IMPELLER/SHAFTSEAL, IMPELLER/SHAFT
-
177522019 SCREWSCREW
-
185630598 WASHERWASHER
-
195131574 HOUSING, PUMP W/RINGHOUSING, PUMP W/RING
-
207555941 WASHER, PUMP STUD SEALWASHER, PUMP STUD SEAL
-
215132111 STUD, MOUNT PUMP LONG INT.STUD, MOUNT PUMP LONG INT.
-
225410652 O-RING, PUMP HOUSING/HULLO-RING, PUMP HOUSING/HULL
-
237080138 CABLE TIECABLE TIE
-
248450054-33 HOSEHOSE
-
255431523 SCREEN, ENGINE INLETSCREEN, ENGINE INLET
-
265130960 NOZZLE, STEERING REVERSENOZZLE, STEERING REVERSE
-
277515366 BOLTBOLT
-
287515361 BOLTBOLT
-
297555874 WASHER, FLATWASHER, FLAT
-
305130938 COLLARCOLLAR
-
315131463 SWIVEL, ROD ENDSWIVEL, ROD END
-
325431765 NOZZLE, TRIMNOZZLE, TRIM
-
337661010 PIN, COTTERPIN, COTTER
-
347552610 WASHER, LOCKWASHER, LOCK
-
357555835 WASHER, FLATWASHER, FLAT
-
365431518 BEARING, STEERING NOZZLEBEARING, STEERING NOZZLE
-
377515389 BOLTBOLT
-
381350038 NOZZLE ASSY.NOZZLE ASSY.
-
395432841 WEDGE, PUMPWEDGE, PUMP
-
407512064 SCREWSCREW
-
415431519 CONE, PUMPCONE, PUMP
-
425811984 SEAL, TAILCONESEAL, TAILCONE
-
435020697 SHAFT, STUBSHAFT, STUB
-
445410818 O-RINGO-RING
-
455410817 O-RINGO-RING
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- BILGE PUMP
- BILGE SIPHON
- CARBURETOR
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- CYLINDER W/ INTAKE
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ENGINE FOGGING SYSTEM
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL / WATER SEPARATOR
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- HULL
- INTAKE GRATE W/ RIDE PLATE
- MAGNETO
- OIL PUMP
- OIL TANK
- • PROPULSION
- SEAT
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- TOOL KIT
- TRIM ASSY.
