CARBURETOR для Polaris PRO 1200 2-Pass - 2001 года выпуска
-
№АртикулНазвание
-
1A1253323 CARBURETOR (KEIHIN)CARBURETOR (KEIHIN)
-
1B2200910 CARBURETOR REBUILD KIT (INCL. 9, 17, 23, 40)CARBURETOR REBUILD KIT (INCL. 9, 17, 23, 40)
-
13050136 SCREWSCREW
-
22200687 FUEL PUMP BODY KIT (KEIHIN)FUEL PUMP BODY KIT (KEIHIN)
-
32200686 GASKET KIT (FUEL PUMP)GASKET KIT (FUEL PUMP)
-
43050254 NOZZEL (PTO) (KEIHIN)NOZZEL (PTO) (KEIHIN)
-
53050143 HOSE, FUELHOSE, FUEL
-
67080138 CABLE TIECABLE TIE
-
77516816 SCREWSCREW
-
85630546 BASE, SILENCER INTAKEBASE, SILENCER INTAKE
-
95830062 GASKET, CARB. (UPPER)GASKET, CARB. (UPPER)
-
103050258 BLOCK, JET (KEIHIN)BLOCK, JET (KEIHIN)
-
112200734 SYNCH.SCREW, KITSYNCH.SCREW, KIT
-
123050156 JOINT, CONNECTINGJOINT, CONNECTING
-
133050157 TUBE, RUBBERTUBE, RUBBER
-
142200685 CHECKVALVE, MID-RANGE KEIHIN) (1 PER CARB)CHECKVALVE, MID-RANGE KEIHIN) (1 PER CARB)
-
153050144 SCREEN, FUEL STRAINERSCREEN, FUEL STRAINER
-
162201309 PUMP, ACCEL. KIT (1 PER CARB.)PUMP, ACCEL. KIT (1 PER CARB.)
-
172200733 NEEDLE VALVE, KIT (1 PER CARB)NEEDLE VALVE, KIT (1 PER CARB)
-
183050186 JET-MAIN, 140 (KEIHIN) (PER CARB) (MAG)JET-MAIN, 140 (KEIHIN) (PER CARB) (MAG)
-
183050187 JET-MAIN, 142 (KEIHIN) (PER CARB) (CENTER)JET-MAIN, 142 (KEIHIN) (PER CARB) (CENTER)
-
183050184 JET-MAIN, 135 (KEIHIN) (PER CARB) (PTO)JET-MAIN, 135 (KEIHIN) (PER CARB) (PTO)
-
193050128 JET-PILOT, 65 (KEIHIN) (1 PER CARB)JET-PILOT, 65 (KEIHIN) (1 PER CARB)
-
203050118 JET-PILOT, 40 (KEIHIN) (1 PER CARB)JET-PILOT, 40 (KEIHIN) (1 PER CARB)
-
213050135 SCREW, JET BLOCK COVERSCREW, JET BLOCK COVER
-
223050139 COVER, JET BLOCKCOVER, JET BLOCK
-
232200730 DIAPHRAGM, JET BLOCK, KIT (1 PER CARB)DIAPHRAGM, JET BLOCK, KIT (1 PER CARB)
-
243050137 SCREW, JET BLOCK (1 PER CARB)SCREW, JET BLOCK (1 PER CARB)
-
253050259 BLOCK, JET KEIHINBLOCK, JET KEIHIN
-
263050147 O-RING, JET BLOCKO-RING, JET BLOCK
-
272200689 IDLESCREW KIT (KEIHIN) (1 PER CARB)IDLESCREW KIT (KEIHIN) (1 PER CARB)
-
283050140 CAP, LIMITERCAP, LIMITER
-
293050138 COLLARCOLLAR
-
303050148 O-RING, VALVE SEATO-RING, VALVE SEAT
-
312200688 CHECKVALVE, MAIN KIT (KEIHIN) (1 PER CARB)CHECKVALVE, MAIN KIT (KEIHIN) (1 PER CARB)
-
322200731 IDLESTOP SCREW KITIDLESTOP SCREW KIT
-
333050252 NOZZLE, (KEIHIN) MAGNOZZLE, (KEIHIN) MAG
-
343050261 HOSE, FUEL (ACCEL.PUMP)HOSE, FUEL (ACCEL.PUMP)
-
353050142 HOSE, FUEL (ACCEL.PUMP)HOSE, FUEL (ACCEL.PUMP)
-
363050141 FITTING, TFITTING, T
-
373050164 PLATE, CONNECTOR (KEIHIN)PLATE, CONNECTOR (KEIHIN)
-
383050159 SCREW, CONNECTOR PLATESCREW, CONNECTOR PLATE
-
393050253 NOZZLE (CENTER) (KEIHIN)NOZZLE (CENTER) (KEIHIN)
-
405830043 GASKET, CARBURETORGASKET, CARBURETOR
