ELECTRICAL BOX для Polaris SLH 2-Pass - 2001 года выпуска
-
№АртикулНазвание
-
17512072 SCREWSCREW
-
27547036 NUTNUT
-
37552615 WASHER, LOCKWASHER, LOCK
-
47555837 WASHER, FLATWASHER, FLAT
-
57555870 WASHER, RUBBERWASHER, RUBBER
-
65211761 PLATE, E-BOX (BOTTOM)PLATE, E-BOX (BOTTOM)
-
74060111 FUSEFUSE
-
84060161 FUSE (3 AMP)FUSE (3 AMP)
-
92460831 HARNESS, WIRE GROUND JUMPERHARNESS, WIRE GROUND JUMPER
-
102460635 HARNESS, TRIMHARNESS, TRIM
-
112460675 HARNESS (60 IN 10 WIRE)HARNESS (60 IN 10 WIRE)
-
124010122 CABLE, RED BATTERY/SOL. CAPCABLE, RED BATTERY/SOL. CAP
-
134010123 CABLE, RED, SOL./STARTER CAPCABLE, RED, SOL./STARTER CAP
-
142460718 HARNESS, 8 WIRE STATORHARNESS, 8 WIRE STATOR
-
154010118 CABLE, GROUND BATTERY/ENGINECABLE, GROUND BATTERY/ENGINE
-
162460931 HARNESS, DIODEHARNESS, DIODE
-
172460928 HARNESS, JUMPERHARNESS, JUMPER
-
187080471 T, CLIPT, CLIP
-
195432502 CAP, GROMMETCAP, GROMMET
-
204010261 PLUG, SEALING WIREPLUG, SEALING WIRE
-
214010302 REGULATOR, RECT/CUTOFFREGULATOR, RECT/CUTOFF
-
222434014 TERM.BOARD ASSY.TERM.BOARD ASSY.
-
237080138 CABLE TIECABLE TIE
-
244010051-05 CONDUIT,CONVOL (15 CM)CONDUIT,CONVOL (15 CM)
-
254010175 CONTROLLER, IGNITIONCONTROLLER, IGNITION
-
265211760 PLATE, TOP E-BOXPLATE, TOP E-BOX
-
272434011 CIRKUT, BREAKER (15A)CIRKUT, BREAKER (15A)
-
285411491 O-RINGO-RING
-
295432503 ELECTRICAL BOX PLASTIC ASSY.ELECTRICAL BOX PLASTIC ASSY.
-
305333544 PIN, LATCHPIN, LATCH
-
315224472 HOOK, 'D'HOOK, 'D'
-
325410853 STRAP, RUBBERSTRAP, RUBBER
-
335242994 BRACKET, BATTERY STRAPBRACKET, BATTERY STRAP
-
347552613 WASHER, LOCKWASHER, LOCK
-
357512043 BOLTBOLT
-
365242995 BRACKET, BATTERY STRAPBRACKET, BATTERY STRAP
-
375411235 GROMMETGROMMET
-
384010404 COIL, IGNITIONCOIL, IGNITION
-
395432569 SEALSEAL
-
405244404 BRACKET, COIL/SOLENOIDBRACKET, COIL/SOLENOID
-
417547061 NUT, NYLOKNUT, NYLOK
-
425521287-53 CONDUIT, FLEX (1.250 ID)CONDUIT, FLEX (1.250 ID)
-
435521286-25 CONDUIT, WIRE (2.5 CM)CONDUIT, WIRE (2.5 CM)
-
443240204 SWITCH, MAGNETOSWITCH, MAGNETO
-
455410346 INSUL.CABLE SOL.INSUL.CABLE SOL.
-
467080461 BOOT, THREADED (RED)BOOT, THREADED (RED)
-
472632136 ELECTRICAL BOX, PLASTIC ASSY. (INCL. 29, 30, 39)ELECTRICAL BOX, PLASTIC ASSY. (INCL. 29, 30, 39)
-
487077691 DECAL, ''RESET ELEC SYSTEM''DECAL, ''RESET ELEC SYSTEM''
-
495432574 PLATE, STATOR 1 HOLEPLATE, STATOR 1 HOLE
-
507555836 WASHERWASHER
-
517515113 BOLTBOLT
