CARBURETOR для Polaris SLX 2-Pass Euro - 2001 года выпуска
-
№АртикулНазвание
-
1A1253323 CARBURETOR (KEIHIN)CARBURETOR (KEIHIN)
-
1B2200910 CARBURETOR BUILD KIT (INCL. 9, 17, 23, 40)CARBURETOR BUILD KIT (INCL. 9, 17, 23, 40)
-
13050136 SCREWSCREW
-
22200687 FUEL PUMP BODY KITFUEL PUMP BODY KIT
-
32200686 GASKET KITGASKET KIT
-
43050254 NOZZEL (PTO)NOZZEL (PTO)
-
53050143 HOSE, FUELHOSE, FUEL
-
67080138 CABLE TIECABLE TIE
-
77516816 SCREWSCREW
-
85630546 BASE, SILENCER INTAKEBASE, SILENCER INTAKE
-
95830062 GASKET, CARBURETOR (UPPER)GASKET, CARBURETOR (UPPER)
-
103050258 BLOCK, JET KEIHINBLOCK, JET KEIHIN
-
112200734 SYNCH.SCREW KITSYNCH.SCREW KIT
-
123050156 JOINT, CONNECTINGJOINT, CONNECTING
-
133050157 TUBE, RUBBERTUBE, RUBBER
-
142200685 CHECK VALVE KIT, MID RANGE (1 PER CARB)CHECK VALVE KIT, MID RANGE (1 PER CARB)
-
153050144 SCREEN, FUEL STRAINERSCREEN, FUEL STRAINER
-
162201309 PUMP, ACCEL. KIT (1 PER CARB)PUMP, ACCEL. KIT (1 PER CARB)
-
172200733 NDLE VALVE KIT (97 DOM) (1 PER CARB)NDLE VALVE KIT (97 DOM) (1 PER CARB)
-
183050186 JET MAIN, 140 KEIHIN (PER CARB) (MAG)JET MAIN, 140 KEIHIN (PER CARB) (MAG)
-
183050187 JET MAIN, 142 KEIHIN (PER CARB) (CENTER)JET MAIN, 142 KEIHIN (PER CARB) (CENTER)
-
183050184 JET MAIN, 135 KEIHIN (PER CARB) (PTO)JET MAIN, 135 KEIHIN (PER CARB) (PTO)
-
193050128 JET PILOT, 65 KEIHIN (1 PER CARB)JET PILOT, 65 KEIHIN (1 PER CARB)
-
203050118 JET PILOT, 40 KEIHIN (1 PER CAR)JET PILOT, 40 KEIHIN (1 PER CAR)
-
213050135 SCREW, JET BLOCK COVERSCREW, JET BLOCK COVER
-
223050139 COVER, JET BLOCKCOVER, JET BLOCK
-
232200730 DIAPHRAGM JET BLOCK KIT (1 PER CARB)DIAPHRAGM JET BLOCK KIT (1 PER CARB)
-
243050137 SCREW, JET BLOCK (1 PER CARB)SCREW, JET BLOCK (1 PER CARB)
-
253050259 BLOCK, JET KEIHINBLOCK, JET KEIHIN
-
263050147 O-RING, JET BLOCKO-RING, JET BLOCK
-
272200689 IDLESCREW KIT (KEIHIN) (1 PER CARB)IDLESCREW KIT (KEIHIN) (1 PER CARB)
-
283050140 CAP, LIMITERCAP, LIMITER
-
293050138 COLLARCOLLAR
-
303050148 O-RING, VALVE SEATO-RING, VALVE SEAT
-
312200688 CHECK VALVE, MAIN KIT (KEIHIN) (1 PER CARB)CHECK VALVE, MAIN KIT (KEIHIN) (1 PER CARB)
-
322200731 IDLESTOP SCREW KITIDLESTOP SCREW KIT
-
333050252 NOZZLE (MAG)NOZZLE (MAG)
-
343050261 HOSE, FUEL (ACCEL PUMP)HOSE, FUEL (ACCEL PUMP)
-
353050142 HOSE, FUEL (ACCEL.PUMP)HOSE, FUEL (ACCEL.PUMP)
-
363050141 FITTING, TFITTING, T
-
373050164 PLATE, CON KEIHINPLATE, CON KEIHIN
-
383050159 SCREW, CONNECTION PLATESCREW, CONNECTION PLATE
-
393050253 NOZZLE (CENTER)NOZZLE (CENTER)
-
405830043 GASKET, CARBURETORGASKET, CARBURETOR
