AIR INLET - ENGINE AND HULL для Polaris Virage 3-Pass - 2001 года выпуска
-
№АртикулНазвание
-
15432138-070 PLUG, INTAKE SILENCER (BLACK)PLUG, INTAKE SILENCER (BLACK)
-
25410589 O-RINGO-RING
-
35132688 STUDSTUD
-
45830062 GASKET, CARBURETOR (UPPER)GASKET, CARBURETOR (UPPER)
-
55631118 BASE, INTAKEBASE, INTAKE
-
67517799 SCREWSCREW
-
72520185 FILTER, INTAKEFILTER, INTAKE
-
85434114-070 COVER, INTAKE W/BLACKCOVER, INTAKE W/BLACK
-
97546708 NUTNUT
-
107661042 RIVET, POPRIVET, POP
-
115433220 FLANGE, INLET AIRFLANGE, INLET AIR
-
125411545 GASKET, INLET AIRGASKET, INLET AIR
-
135812108 PANEL, AIR DUCT VIRAGEPANEL, AIR DUCT VIRAGE
-
145411958 GASKET, AIR DUCT PANEL VIRAGEGASKET, AIR DUCT PANEL VIRAGE
-
157080439 CLAMP, HOSECLAMP, HOSE
-
165433082 DUCT, INLET AIRDUCT, INLET AIR
-
177080492 STRAP, WEATHER RESIST. (BLACK)STRAP, WEATHER RESIST. (BLACK)
Все узлы модели:
- • AIR INLET - ENGINE AND HULL
- BATTERY BOX
- BILGE PUMP
- CARBURETOR
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- CYLINDER W/ INTAKE
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ENGINE FOGGING SYSTEM
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL / WATER SEPARATOR
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- INTAKE GRATE W/ RIDE PLATE
- MAGNETO
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD W/ INSTRUMENTS AND MIRRORS
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- TOOL KIT
