SHROUD W/ INSTRUMENTS AND MIRRORS для Polaris Virage TX 3-Pass Euro - 2001 года выпуска`
-
№АртикулНазвание
-
13280365 GAUGE, MFI, VIRAGE RVS RPM LIMITGAUGE, MFI, VIRAGE RVS RPM LIMIT
-
25411738 GASKET, MFIGASKET, MFI
-
38450070-190 PITOT LINE, 90DEG FORMED (345 CM.)PITOT LINE, 90DEG FORMED (345 CM.)
-
47041931 SPRING, MOUNTING MFISPRING, MOUNTING MFI
-
52201593 MFI, BUTTON REPLACEMENT KITMFI, BUTTON REPLACEMENT KIT
-
63280342 BEZEL-MFI, OVERLAYBEZEL-MFI, OVERLAY
-
75434176-310 LID, CONSOLE, HAV RED METLID, CONSOLE, HAV RED MET
-
87042007 SPRING, TORTIONSPRING, TORTION
-
95521579 SEAL, LID PORONSEAL, LID PORON
-
107546705 NUTNUT
-
115812235 PADPAD
-
127517668 SCREWSCREW
-
137555874 WASHER, FLATWASHER, FLAT
-
147546704 NUT, NYLOKNUT, NYLOK
-
157556094 WASHERWASHER
-
165245455 HOOK, LATCHHOOK, LATCH
-
177517669 SCREWSCREW
-
185411557 GASKET, MIRROR (LEFT)GASKET, MIRROR (LEFT)
-
185411558 GASKET, MIRROR (RIGHT)GASKET, MIRROR (RIGHT)
-
192631972-070 MIRROR ASSY. (LEFT/BLACK)MIRROR ASSY. (LEFT/BLACK)
-
192631973-070 MIRROR ASSY. (RIGHT/BLACK)MIRROR ASSY. (RIGHT/BLACK)
-
207546804 NUT, HEX NYLOKNUT, HEX NYLOK
-
217546704 NUT, NYLOKNUT, NYLOK
-
227555839 WASHER, FLATWASHER, FLAT
-
237541931 NUT, HEXNUT, HEX
-
247080788 CABLE, CHOKE THICK NECKCABLE, CHOKE THICK NECK
-
255244673 BRACKET, SUPPORT SHROUDBRACKET, SUPPORT SHROUD
-
267516807 BOLTBOLT
-
275411664 GROMMET, DECK WIRE HARNESSGROMMET, DECK WIRE HARNESS
-
282690151 STRAP, TOOL KIT (LOWER)STRAP, TOOL KIT (LOWER)
-
295433210-070 COVER, WIRE SHROUD (BLACK)COVER, WIRE SHROUD (BLACK)
-
312690150 STRAP, TOOL KIT (UPPER)STRAP, TOOL KIT (UPPER)
-
327710517 RING, RETAININGRING, RETAINING
-
337516805 SCREWSCREW
-
347552613 WASHER, LOCKWASHER, LOCK
-
357556094 WASHERWASHER
-
365434218-310 SHROUD W/LID KITSHROUD W/LID KIT
-
375812076 BUMPER, DOOR/SHROUDBUMPER, DOOR/SHROUD
-
382080004 KNOB, CHOKEKNOB, CHOKE
-
392080005 SCREWSCREW
-
405244670 PLATE, LATCH RECEIVERPLATE, LATCH RECEIVER
-
417555837 WASHER, FLATWASHER, FLAT
-
427517879 SCREWSCREW
-
435333698 PIN, HINGEPIN, HINGE
-
445433384 HINGE, 3/16 PINHINGE, 3/16 PIN
-
452653011 LATCH ASSY., CONSOLELATCH ASSY., CONSOLE
