STEERING CABLE ASSY. для Polaris Virage TXi 3-Pass Euro - 2001 года выпуска
-
№АртикулНазвание
-
17542150 NUTNUT
-
27515120 BOLTBOLT
-
37555839 WASHER, FLATWASHER, FLAT
-
47060170 ROD ENDROD END
-
57542133 NUT, NYLOKNUT, NYLOK
-
61860115 SEAL, WASHER STEERINGSEAL, WASHER STEERING
-
71860117 WASHER, CLIP STEERING CABLEWASHER, CLIP STEERING CABLE
-
81860114 NUT. SPECIALNUT. SPECIAL
-
97080723 CABLE, STEERING EXT PUMPCABLE, STEERING EXT PUMP
-
105244681 BRACE, STEERING CABLEBRACE, STEERING CABLE
-
117556094 WASHERWASHER
-
127516717 BOLTBOLT
-
137542528 NUTNUT
-
141860103 WASHERWASHER
-
157571625 WASHER, LOCKWASHER, LOCK
-
161860105 COVERCOVER
-
177080931 TUBE ASSY., GUIDE (5.2 INCH)TUBE ASSY., GUIDE (5.2 INCH)
-
187060154 ROD, ENDROD, END
-
197555837 WASHER, FLATWASHER, FLAT
-
207541931 NUT, HEXNUT, HEX
-
217512041 BOLTBOLT
-
225132317 COLUMN, STEERINGCOLUMN, STEERING
-
237546704 NUT, NYLOKNUT, NYLOK
-
245244290 BRACKET, STEERING CABLEBRACKET, STEERING CABLE
Все узлы модели:
- AIR INLET - ENGINE AND HULL
- AIR INTAKE SYSTEM
- BATTERY BOX
- BILGE PUMP
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ELECTRONIC MODULE
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- INTAKE GRATE W/ RIDE PLATE
- MANIFOLD- CYLINDER W/ IGNITION
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD W/ INSTRUMENTS AND MIRRORS
- STARTING MOTOR
- • STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- THROTTLE BODY ASSY.
- TOOL KIT
