FUEL SYSTEM для Polaris Genesis i 4-Pass Euro - 2002 года выпуска
-
№АртикулНазвание
-
15410682 GROMMET, VENTGROMMET, VENT
-
27080483 CABLE TIE (4 INCH)CABLE TIE (4 INCH)
-
37052078 CONNECTORCONNECTOR
-
47080138 CABLE TIECABLE TIE
-
57080476 CLAMP, HOSECLAMP, HOSE
-
67051015 VALVE, CHECK RELIEFVALVE, CHECK RELIEF
-
77052111 FITTING, TEEFITTING, TEE
-
87052118 VALVE, VACUUM CHECKVALVE, VACUUM CHECK
-
98450046-1525 FUEL LINE (1/4'' 250CM) (OPT)FUEL LINE (1/4'' 250CM) (OPT)
-
107052253 CONNECTOR ASSY.CONNECTOR ASSY.
-
117052329 FITTING, STRAIGHTFITTING, STRAIGHT
-
127080482 T-CLIPT-CLIP
-
137052230 FITTING-T (LARGE)FITTING-T (LARGE)
-
148450085 SPACER (OPT)SPACER (OPT)
-
157052229 FITTING-L (LARGE)FITTING-L (LARGE)
-
165411601 O-RING (LARGE)O-RING (LARGE)
-
177052227 FITTING-L (SMALL)FITTING-L (SMALL)
-
185411599 O-RING (SMALL)O-RING (SMALL)
-
191253349 INJECTORINJECTOR
-
207052228 FITTING-T (SMALL)FITTING-T (SMALL)
-
217080948 CLAMP, HOSECLAMP, HOSE
-
222872602 SHRADER VALVE, W/ CAPSHRADER VALVE, W/ CAP
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- BILGE PUMP
- BILGE SIPHON
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ELECTRONIC MODULE
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- • FUEL SYSTEM
- FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- HULL
- INTAKE GRATE W/ RIDE PLATE
- MANIFOLD- CYLINDER W/ IGNITION
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD W/ INSTRUMENTS AND MIRRORS
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- THROTTLE BODY ASSY.
- TOOL KIT
