ELECTRICAL BOX для Polaris Virage 3-Pass - 2002 года выпуска
-
№АртикулНазвание
-
12460955 HARNESS, MAIN VIRAGE W/O SPLICEHARNESS, MAIN VIRAGE W/O SPLICE
-
25521287-53 CONDUIT, FLEX (1.250 ID)CONDUIT, FLEX (1.250 ID)
-
37080138 CABLE TIECABLE TIE
-
47080483 CABLE TIE (4 IN.)CABLE TIE (4 IN.)
-
55410346 INSUL.CABLE SOL.INSUL.CABLE SOL.
-
67546705 NUTNUT
-
77552613 WASHER, LOCKWASHER, LOCK
-
84010401 SOLENOID, STARTERSOLENOID, STARTER
-
97517671 SCREWSCREW
-
107555839 WASHER, FLATWASHER, FLAT
-
117546704 NUT, NYLOKNUT, NYLOK
-
124060161 FUSE (3 AMP)FUSE (3 AMP)
-
134060111 FUSEFUSE
-
142460928 HARNESS, JUMPERHARNESS, JUMPER
-
155432503 ELECTRICAL BOX PLASTIC ASSY.ELECTRICAL BOX PLASTIC ASSY.
-
165333544 PIN, LATCHPIN, LATCH
-
174010568 CONTROLLER, IGNITIONCONTROLLER, IGNITION
-
182410250 STRAP ASSY., GROUNDING W/FUSESSTRAP ASSY., GROUNDING W/FUSES
-
197547061 NUT, NYLOKNUT, NYLOK
-
207555837 WASHER, FLATWASHER, FLAT
-
217512042 BOLTBOLT
-
224010648 REGULATOR, 1 BUTTONREGULATOR, 1 BUTTON
-
237547059 NUT, NYLOKNUT, NYLOK
-
244010238 CABLE, BATTERYERY/SOLENOIDCABLE, BATTERYERY/SOLENOID
-
254010237 CABLE, SOLENOID/STARTERCABLE, SOLENOID/STARTER
-
265411491 O-RINGO-RING
-
277080461 BOOT, THREADED (RED)BOOT, THREADED (RED)
-
287515113 BOLTBOLT
-
297555836 WASHERWASHER
-
305432574 PLATE, STATOR 1 HOLEPLATE, STATOR 1 HOLE
-
317073734 DECALDECAL
-
322460718 HARNESS, 8 WIRE STATORHARNESS, 8 WIRE STATOR
-
335433119 COVER, ACCESSORY E-BOXCOVER, ACCESSORY E-BOX
-
345432569 SEALSEAL
-
355244370 BRACKET, COILBRACKET, COIL
-
364010175 COIL, IGNITIONCOIL, IGNITION
-
372410201 BOARD ASSY., TERMINALBOARD ASSY., TERMINAL
-
382434011 CIRKUT BREAKER (15A)CIRKUT BREAKER (15A)
-
392632137 ELECTRICAL BOX, IGNITION ASSY. (INCL. 15, 16, 33, 34)ELECTRICAL BOX, IGNITION ASSY. (INCL. 15, 16, 33, 34)
-
405411235 GROMMETGROMMET
-
415432502 CAP, GROMMETCAP, GROMMET
-
424010261 PLUG, SEALING WIREPLUG, SEALING WIRE
-
437517825 SCREWSCREW
