CYLINDER W/ INTAKE для Polaris Virage i 3-Pass - 2002 года выпуска
-
№АртикулНазвание
-
17051527 PLUG, PIPEPLUG, PIPE
-
27077026 DECAL, SPARKPLUG REC.DECAL, SPARKPLUG REC.
-
37075383 DECAL, WARNINGDECAL, WARNING
-
47516806 BOLTBOLT
-
51202061-067 WATER MANIFOLD ASSY. (BLACK)WATER MANIFOLD ASSY. (BLACK)
-
65830061 GASKET, WATER MANIFOLDGASKET, WATER MANIFOLD
-
75244008 RESTRICTOR, CYLINDER HEADRESTRICTOR, CYLINDER HEAD
-
87661072 RIVETRIVET
-
95411573 O-RINGO-RING
-
105410931 O-RINGO-RING
-
117547021 NUTNUT
-
127556222 WASHER FLATWASHER FLAT
-
133021286 CYLINDERCYLINDER
-
145811784 GASKET, CYLINDER BASEGASKET, CYLINDER BASE
-
157516807 BOLTBOLT
-
167516814 BOLTBOLT
-
177052156 FITTING, HOSE (1/4'')FITTING, HOSE (1/4'')
-
187080830 CLAMP, HOSECLAMP, HOSE
-
198450085-100 HOSE (OPT)HOSE (OPT)
-
207080654 RETAINERRETAINER
-
211202380-329 MANIFOLD, INTAKE (BLACK)MANIFOLD, INTAKE (BLACK)
-
225830043 GASKET, CARBURETORGASKET, CARBURETOR
-
235433151 STUFFER REED BLOCKSTUFFER REED BLOCK
-
241201825 VALVE, REED ASSY.VALVE, REED ASSY.
-
253070189 SPARK, PLUGSPARK, PLUG
-
263021205-244 HEAD CYLINDER (SILVER)HEAD CYLINDER (SILVER)
-
271253375 FUEL KITFUEL KIT
-
281202086 PDS CAP ASSY.PDS CAP ASSY.
-
297555835 WASHER, FLATWASHER, FLAT
-
307517832 SCR OMC, SPECIALSCR OMC, SPECIAL
-
315411876 O-RINGO-RING
-
327516721 BOLTBOLT
