COOLING SYSTEM для Polaris Virage TX 3-Pass Euro - 2002 года выпуска
-
№АртикулНазвание
-
15811317 GASKETGASKET
-
25431444-133 FITTING, THRU HULL (WHITE)FITTING, THRU HULL (WHITE)
-
37080475 CLAMP, HOSECLAMP, HOSE
-
45521287-18 CONDUIT, FLEX (1.250 ID)CONDUIT, FLEX (1.250 ID)
-
55411335 HOSE, WATER INLETHOSE, WATER INLET
-
65431784 FITTING, TEEFITTING, TEE
-
75411793 HOSE, WATER-IN EXHAUST PIPEHOSE, WATER-IN EXHAUST PIPE
-
85020668 FITTING, INLET WATERFITTING, INLET WATER
-
97052105 FITTING, EXHAUST SCREENFITTING, EXHAUST SCREEN
-
107080476 CLAMP, HOSECLAMP, HOSE
-
115411153 HOSE, STINGERHOSE, STINGER
-
127052290 FITTING, INJECTOR EXHAUSTFITTING, INJECTOR EXHAUST
-
135410897 HOSE, STINGER FORMEDHOSE, STINGER FORMED
-
145521398-42 CONDUIT, FLEXCONDUIT, FLEX
-
157516727 BOLTBOLT
-
167516725 BOLTBOLT
-
171260809-329 MANIFOLD, EXHAUST ASSY. (BLACK)MANIFOLD, EXHAUST ASSY. (BLACK)
-
185020746 FITTING, DRAINFITTING, DRAIN
-
197080138 CABLE TIECABLE TIE
-
207051527 PLUG, PIPEPLUG, PIPE
-
217051008 THERMOSTAT (143 F.)THERMOSTAT (143 F.)
-
225412014 GASKET, THERMOSTATGASKET, THERMOSTAT
-
237556174 WASHER, ANODIZEWASHER, ANODIZE
-
245631136 COVER, THERMOSTATCOVER, THERMOSTAT
-
257041310 SPRING, COMPRESSIONSPRING, COMPRESSION
-
265433823 VALVE, POP OFFVALVE, POP OFF
-
275410860 SEAL, O-RING/THERMO/FITTINGSEAL, O-RING/THERMO/FITTING
-
285411310 HOSE, WATER OUT (3/4 ID)HOSE, WATER OUT (3/4 ID)
-
295521287-45 CONDUIT, FLEX (1.250 ID)CONDUIT, FLEX (1.250 ID)
