FUEL TANK для Polaris Genesis i 4-Pass - 2003 года выпуска
-
№АртикулНазвание
-
1A2632743 STRAP ASSY. (INCL. 2, 3)STRAP ASSY. (INCL. 2, 3)
-
15412305 STRAP, CONNECTINGSTRAP, CONNECTING
-
25521615 COVER, STRAPCOVER, STRAP
-
35434786 STRAP ASSY.STRAP ASSY.
-
47621478 RIVETRIVET
-
55246707 BRACKET, TANK STRAPBRACKET, TANK STRAP
-
65433259 NUTNUT
-
72410129 PUMP, FUEL ELECTRICPUMP, FUEL ELECTRIC
-
85411636 GASKETGASKET
-
95434873 TANK, FUELTANK, FUEL
-
107621479 RIVETRIVET
-
117555837 WASHER, FLATWASHER, FLAT
-
125811999 PAD, FUEL TANK (REAR)PAD, FUEL TANK (REAR)
-
135812152 PADPAD
-
145811901 PAD, TANK FUEL SIDEPAD, TANK FUEL SIDE
-
157080451 CLAMP, HOSECLAMP, HOSE
-
165411546 HOSE, FILL FUELHOSE, FILL FUEL
-
177080766 CLAMP, HOSECLAMP, HOSE
-
185433621 NUT, INLET FUELNUT, INLET FUEL
-
195811492 SEAL, FUEL INLETSEAL, FUEL INLET
-
205433553 INLET, FUELINLET, FUEL
-
215411305 SEAL, FUEL CAPSEAL, FUEL CAP
-
222520177 CAP, FUEL RATCHET ASSY.CAP, FUEL RATCHET ASSY.
-
237621229 RIVETRIVET
-
247080710 CHAIN, BEADCHAIN, BEAD
-
257511873 SCREWSCREW
-
267080442 COUPLING, ENDCOUPLING, END
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY BOX
- BILGE PUMP
- BILGE SIPHON
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTONS
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL COMPONENTS
- ELECTRONIC MODULE
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL SYSTEM
- • FUEL TANK
- HANDLEBAR ASSY. W/ STEERING COLUMN
- HULL
- HULL
- INTAKE GRATE W/ RIDE PLATE
- MANIFOLD- CYLINDER W/ IGNITION
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD W/ INSTRUMENTS AND MIRRORS
- STARTING MOTOR
- STEERING CABLE ASSY.
- STORAGE COMPARTMENT - FRONT
- THROTTLE BODY ASSY.
- TOOL KIT
