COOLING SYSTEM для Polaris Virage i 3-Pass Euro - 2003 года выпуска
-
№АртикулНазвание
-
15811317 GASKETGASKET
-
25431444-133 FITTING, THRU HULL (WHITE)FITTING, THRU HULL (WHITE)
-
37080475 CLAMP, HOSECLAMP, HOSE
-
45132309 FITTING, WATERFITTING, WATER
-
55521287-45 CONDUIT, FLEX (1.250 ID)CONDUIT, FLEX (1.250 ID)
-
65431784 FITTING, TEEFITTING, TEE
-
77080476 CLAMP, HOSECLAMP, HOSE
-
88450054-100 HOSE, WATERHOSE, WATER
-
97052128 FITTING, SCREENFITTING, SCREEN
-
105020747 FITTING, INJECTORFITTING, INJECTOR
-
118450102 HOSE (1/4'' IDX2'')HOSE (1/4'' IDX2'')
-
127052135 FITTINGFITTING
-
137555841 WASHER, FLATWASHER, FLAT
-
144010768 SOLENOID, INJECT DERLINSOLENOID, INJECT DERLIN
-
157052065 FITTING, 90 DEGREEFITTING, 90 DEGREE
-
165521398-52 CONDUIT, FLEX (.75''ID)CONDUIT, FLEX (.75''ID)
-
178450104-1525 FUEL LINE (1/4'', 250CM) (OPT)FUEL LINE (1/4'', 250CM) (OPT)
-
187052075 FITTING, TEEFITTING, TEE
-
197080138 CABLE TIECABLE TIE
-
207516727 BOLTBOLT
-
217516725 BOLTBOLT
-
221260694-329 MANIFOLD, EXHAUST ASSY. (BLACK)MANIFOLD, EXHAUST ASSY. (BLACK)
-
235811045 GASKET, EXHAUST FLANGEGASKET, EXHAUST FLANGE
-
247555856 WASHER, FLATWASHER, FLAT
-
257552611 WASHER, LOCKWASHER, LOCK
-
267517004 BOLTBOLT
-
275020746 FITTING, DRAINFITTING, DRAIN
-
287051008 THERMOSTAT (143 F.)THERMOSTAT (143 F.)
-
295412014 GASKET, THERMOSTATGASKET, THERMOSTAT
-
307556174 WASHER, ANODIZEWASHER, ANODIZE
-
315631136 COVER, THERMOSTATCOVER, THERMOSTAT
-
327041310 SPRING, COMPRESSIONSPRING, COMPRESSION
-
335432799 VALVE, POP OFFVALVE, POP OFF
-
345410860 SEAL, O-RING/THERMO/FITTINGSEAL, O-RING/THERMO/FITTING
-
355521398-13 CONDUIT, FLEX (.75''ID)CONDUIT, FLEX (.75''ID)
-
365411049 HOSE, PUMP OUTLETHOSE, PUMP OUTLET
-
378450050-08 HOUSEHOUSE
-
385411479 HOSE, WATER OUT (3/4 ID)HOSE, WATER OUT (3/4 ID)
-
395411050 HOSE, INLETHOSE, INLET
