ENGINE FOGGING SYSTEM для Polaris VIRAGE (DA) - 2004 года выпуска
-
№АртикулНазвание
-
17080138 CABLE TIECABLE TIE
-
27080484 CLAMP, HOSECLAMP, HOSE
-
37080476 CLAMP, HOSE, S.S.CLAMP, HOSE, S.S.
-
47052139 FITTING, TFITTING, T
-
57075738 DECAL, PRIMER, ENG. FOGGERDECAL, PRIMER, ENG. FOGGER
-
68450062 OIL LINE, 132 CM.OIL LINE, 132 CM.
-
73160114 PRIMER, ENG., FOGPRIMER, ENG., FOG
-
127075732 DECAL, ''FOG.OIL ONLY''DECAL, ''FOG.OIL ONLY''
-
137555837 WASHER, FLAT, S.S.WASHER, FLAT, S.S.
-
147541931 NUT, HEX, S.S.NUT, HEX, S.S.
-
157052047 SS TO 7051011: VALVE, CHECKSS TO 7051011: VALVE, CHECK
-
167052138 FITTING, 90 DEG.FITTING, 90 DEG.
-
175432362 TANK, OIL, FOG KITTANK, OIL, FOG KIT
-
185810279 GASKETGASKET
-
195432359 CAP, OIL BOTTLECAP, OIL BOTTLE
-
207512045 BOLT, SS.BOLT, SS.
-
215244295 BRACKET, BOTTLE, FOGBRACKET, BOTTLE, FOG
-
-2872635 FOOGING SYSTEMFOOGING SYSTEM
