INTAKE GRATE W/ RIDE PLATE для Polaris VIRAGE I (IA) - 2004 года выпуска
-
№АртикулНазвание
-
17080483 CABLE TIE, 4 INCHCABLE TIE, 4 INCH
-
37547003 NUTNUT
-
47555873 WASHER, FLAT, NYLONWASHER, FLAT, NYLON
-
55810879 GASKET, PITOTGASKET, PITOT
-
67555848 WASHER, FLAT, S.S.WASHER, FLAT, S.S.
-
75431634 FITTING, PILOT, MOLDEDFITTING, PILOT, MOLDED
-
85133650 SCOOP-INLET, 2SCOOP-INLET, 2
-
97081117 VELCRO-TIE STRAP, 1/2" X 6''VELCRO-TIE STRAP, 1/2" X 6''
-
105630542-067 GRATE, INLET, CAST, BLACK.GRATE, INLET, CAST, BLACK.
-
117515155 BOLT, S.S.BOLT, S.S.
-
127517267 SCREWSCREW
-
137515126 BOLT, SSBOLT, SS
-
145631080-329 PLATE-RIDE, HP, BLACKPLATE-RIDE, HP, BLACK
-
157010083 INSERT, SPONSON / RIDEPLATEINSERT, SPONSON / RIDEPLATE
Все узлы модели:
- AIR INTAKE SYSTEM
- BATTERY
- BILGE PUMP
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTON
- CYLINDER AND MANIFOLD
- DECALS
- DRIVE SHAFT W/ COUPLER
- ELECTRICAL BOX
- ELECTRICAL BOX
- ENGINE FOGGING SYSTEM
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL SYSTEM
- FUEL TANK
- HANDLEBAR W/ COVER
- HULL AIR INLET
- HULL AND BODY
- • INTAKE GRATE W/ RIDE PLATE
- MAGNETO
- OIL PUMP
- OIL TANK
- PROPULSION
- REVERSE
- SEAT
- SHROUD
- STARTING MOTOR
- STEERING CABLE ASSY. - REAR
- STORAGE COMPARTMENT - FRONT
- THROTTLE BODY
- TOOL KIT
