FUEL TANK для Polaris VIRAGE (IA) - 2004 года выпуска
-
№АртикулНазвание
-
15244279 BRKT-STRAP, 5/16 BOLTBRKT-STRAP, 5/16 BOLT
-
27552610 WASHER, LOCK, S.S.WASHER, LOCK, S.S.
-
37515361 BOLT, S.S.BOLT, S.S.
-
45243775 HOOK, STRAP, NARROWHOOK, STRAP, NARROW
-
55430621 STRAPSTRAP
-
75243776 HOOK, STRAP, 180 DEG RETURNHOOK, STRAP, 180 DEG RETURN
-
85410424 SS TO 5412499: STRAP-BATTERY HOLD DOWN-CSS TO 5412499: STRAP-BATTERY HOLD DOWN-C
-
92520177 ASM., CAP, FUEL, RATCHETASM., CAP, FUEL, RATCHET
-
107080710 CHAIN, BEADCHAIN, BEAD
-
117511873 SCREWSCREW
-
127080442 COUPLING, ENDCOUPLING, END
-
135433553 INLET, FUELINLET, FUEL
-
145811492 SEAL, FUEL INLETSEAL, FUEL INLET
-
155433621 NUT, INLET, FUELNUT, INLET, FUEL
-
167080766 CLAMP, HOSE, SS. (IF BUILT BEFORE 12/29/03)CLAMP, HOSE, SS. (IF BUILT BEFORE 12/29/03)
-
165433259 NUT (IF BUILT AFTER 12/29/03)NUT (IF BUILT AFTER 12/29/03)
-
175411757 HOSE, FUEL FILLHOSE, FUEL FILL
-
187080451 CLAMP, HOSE, S.S.CLAMP, HOSE, S.S.
-
192410124 SENDER, PICKUP, ASM.17 GAL (IF BUILT BEFORE 12/29/03)SENDER, PICKUP, ASM.17 GAL (IF BUILT BEFORE 12/29/03)
-
192410521 FUEL SENDER ASM (IF BUILT AFTER 12/29/03)FUEL SENDER ASM (IF BUILT AFTER 12/29/03)
-
192410520 HARNESS-ADAPTER, CARB, FED, MOG (IF BUILT AFTER 12/29/03)HARNESS-ADAPTER, CARB, FED, MOG (IF BUILT AFTER 12/29/03)
-
205411636 GASKETGASKET
-
217621407 RIVETRIVET
-
225812206 PAD-FUEL TANK STOP, 5/16PAD-FUEL TANK STOP, 5/16
-
235244758 BRKT, FUEL TANK STOPBRKT, FUEL TANK STOP
-
245812152 PAD-EVA, 26'' X 5'' X .22PAD-EVA, 26'' X 5'' X .22
-
255434914 TANK-FUEL, 17 GAL, W/RELIEF, CARB (IF BUILT BEFORE 12/29/03)TANK-FUEL, 17 GAL, W/RELIEF, CARB (IF BUILT BEFORE 12/29/03)
-
255434872 TANK-FUEL, LTR, W/RELIEF, DFI (IF BUILT AFTER 12/29/03)TANK-FUEL, LTR, W/RELIEF, DFI (IF BUILT AFTER 12/29/03)
-
267621229 RIVETRIVET
-
275411305 SEAL, FUEL CAPSEAL, FUEL CAP
