OIL TANK ASSEMBLY для Polaris 800 RMK (S00SR8BS) - 2000 года выпуска
-
№АртикулНазвание
-
17077442 DECAL, FUEL SHUT-OFFDECAL, FUEL SHUT-OFF
-
21253316 ASSY. OIL TANK W/FOIL, LIQASSY. OIL TANK W/FOIL, LIQ
-
35811934 FOIL, OIL TANKFOIL, OIL TANK
-
47512276 BOLTBOLT
-
57558302 WASHER, WROUGHTWASHER, WROUGHT
-
67670096 NUTNUT
-
74110134 SENSOR, OIL LEVELSENSOR, OIL LEVEL
-
82511287 CAP-OIL, VENTED/CUSTOM COLORCAP-OIL, VENTED/CUSTOM COLOR
-
92511270 CAP, PRESSURE, (13 LB)CAP, PRESSURE, (13 LB)
-
107078369 DECAL-SURGE TANK, ''FULL COLD''DECAL-SURGE TANK, ''FULL COLD''
-
137517455 SCREWSCREW
-
147052028 GROMMET-TANK FITTINGGROMMET-TANK FITTING
-
157052207 FTTNG, STRAIGHT, PRESS-INFTTNG, STRAIGHT, PRESS-IN
-
167517615 SCREWSCREW
-
177080367 CLAMP, CABLECLAMP, CABLE
-
187621432 RIVET (3/16X.402)RIVET (3/16X.402)
-
195242680 BRACKET, FUEL PUMP MOUNT-ZBRACKET, FUEL PUMP MOUNT-Z
-
207542122 NUT-LOCKNUT-LOCK
-
211012947 BRACKET, CDI MOUNT, 110MM-ZBRACKET, CDI MOUNT, 110MM-Z
-
227555746 BURR, RIVETBURR, RIVET
-
237541925 NUTNUT
-
245243636 BRACKET, OIL/COOLANT TANK, ALUMBRACKET, OIL/COOLANT TANK, ALUM
-
254020139 CLIP, PLASTICCLIP, PLASTIC
-
267080307 CLAMPCLAMP
-
278450003-1525 FUEL LINE, 1/4 ID (1525 CM.)FUEL LINE, 1/4 ID (1525 CM.)
-
282530009 FILTER, SMALL, IN-LINEFILTER, SMALL, IN-LINE
