CLUTCH - DRIVE для Polaris 700 RMK 144 STOCK (S02NK7CSA) - 2002 года выпуска

№

Артикул

Название
1

7512265 BOLT

BOLT

630 ₽
2

7552801 WASHER, SPRING LOCK

WASHER, SPRING LOCK

460 ₽
3

3576516 BEARING, COVER

BEARING, COVER

4 160 ₽
4

7710417 RING, RETAINING, COVER

RING, RETAINING, COVER

150 ₽
5

7041945 SPRING-CLUTCH(ALMOND/ROUND)

SPRING-CLUTCH(ALMOND/ROUND)

9 780 ₽
6

5430945 WASHER

WASHER

420 ₽
7

1321622 ROLLER AND BUSHING ASSY.

ROLLER AND BUSHING ASSY.

8 110 ₽
8

5430445 BUTTON, GUIDE

BUTTON, GUIDE

1 460 ₽
9

1321684 WT/BUSH.ASSY., 10-56(3)

WT/BUSH.ASSY., 10-56(3)

6 240 ₽
10

7515105 PIN, WT., HARDENED

PIN, WT., HARDENED

1 870 ₽
11

3576502 BEARING, SLEEVE

BEARING, SLEEVE

4 990 ₽
12

5010188 INSERT, MOVEABLE

INSERT, MOVEABLE

1 520 ₽
13

7541906 NUT FLEXLOC

NUT FLEXLOC

250 ₽
14

5210754 SPACER, .050 (.050MM)

SPACER, .050 (.050MM)

580 ₽
14

5210753 SPACER, .032 (.032MM)

SPACER, .032 (.032MM)

420 ₽
14

5242981 SPACER, .025 (.025 MM)

SPACER, .025 (.025 MM)

260 ₽
14

5210752 SPACER, .020 (.020MM)

SPACER, .020 (.020MM)

110 ₽
15

5020425 NUT, JAM

NUT, JAM

4 370 ₽
16

5020422 PIN-ROLLER,

PIN-ROLLER,

670 ₽
17

2200387 SHIM KIT, DRIVE CLUTCH

SHIM KIT, DRIVE CLUTCH

2 910 ₽
18

1321928 DRIVE CLUTCH ASSY., BASIC, 114 W/B (INCL. ALL LESS 5, 9)

DRIVE CLUTCH ASSY., BASIC, 114 W/B (INCL. ALL LESS 5, 9)

122 780 ₽
18

2201169 WIDE ROLLER SPIDER REBUILD KIT (INCL. 6-8, 10, 16, 17)

WIDE ROLLER SPIDER REBUILD KIT (INCL. 6-8, 10, 16, 17)

33 280 ₽
