HANDLEBAR ASSEMBLY W/ CONTROLS для Polaris 600 HO IQ CLEAN RIFE F/O (S07PP6HS) - 2007 года выпуска
-
№АртикулНазвание
-
15435394-070 GRIP-HANDLEBAR, BLACK (HOOK STYLE)GRIP-HANDLEBAR, BLACK (HOOK STYLE)
-
27555730 WASHERWASHER
-
37661624 PIN-RETAININGPIN-RETAINING
-
47710503 RING, RETAININGRING, RETAINING
-
55432970 THROTTLE, LEVER, 35.5MMTHROTTLE, LEVER, 35.5MM
-
52010271 ASM-LEVER, HTR, HI/LO 35.5MMASM-LEVER, HTR, HI/LO 35.5MM
-
64011540 SWITCH-AUX SHUT-OFF, HONSWITCH-AUX SHUT-OFF, HON
-
75430604 BLOCK-ADAPTERBLOCK-ADAPTER
-
85249859-067 BAR-HANDLE, BLACK (HOOK STYLE)BAR-HANDLE, BLACK (HOOK STYLE)
-
97512329 BOLTBOLT
-
107558402 WASHER, FLATWASHER, FLAT
-
112683859 ASM-HANDLEBAR COVER, RACEASM-HANDLEBAR COVER, RACE
-
125631311 CLAMP-HANDLE BAR, RETAINERCLAMP-HANDLE BAR, RETAINER
-
132410777 HEATER-GRIP, LO/MED/HI, SHORT (HOOK STYLE)HEATER-GRIP, LO/MED/HI, SHORT (HOOK STYLE)
-
141253274-070 HOOK, HNDLBAR, 45DEG, BLKHOOK, HNDLBAR, 45DEG, BLK
-
157517834 SCR-SOCKET HEAD, SS5/16-18X3.00SCR-SOCKET HEAD, SS5/16-18X3.00
-
165433291 BUTTON SWITCH HI/LO, LEFT HAND CONTROLBUTTON SWITCH HI/LO, LEFT HAND CONTROL
-
172010237 ASM-CONTROL, LH, MFG (INCL. 16)ASM-CONTROL, LH, MFG (INCL. 16)
-
187517566 SCREW, 1.50SCREW, 1.50
-
197512078 SCREW, 1.12SCREW, 1.12
-
207517441 SCREW, .75SCREW, .75
-
215133793 BLOXK-HANDLEBAR RISER, 2.38BLOXK-HANDLEBAR RISER, 2.38
-
227081332 CABLE-THROTTLE, SDICABLE-THROTTLE, SDI
-
237511848 SCREWSCREW
-
245432261 HOLDER-WIREHOLDER-WIRE
-
257555727 WASHERWASHER
-
267512465 SCREW, SETSCREW, SET
-
275431592 BLOCK, THROTTLE/BRAKEBLOCK, THROTTLE/BRAKE
-
287710401 RING, RETAININGRING, RETAINING
