WATER PUMP/OIL PUMP для Polaris 600 HO LX CLEAN FIRE (S07PD6HS) - 2007 года выпуска
-
№АртикулНазвание
-
15411197 SEAL, TYPE S, ARSSEAL, TYPE S, ARS
-
23610067 SEALSEAL
-
37556006 WASHER, FLAT, SS.WASHER, FLAT, SS.
-
45436648 IMPELLER-WATERPUMPIMPELLER-WATERPUMP
-
57547332 NUT-M8X1.25, FLG, NYLOC-OLIVE DNUT-M8X1.25, FLG, NYLOC-OLIVE D
-
65811601 GASKET, WATERPUMP CVR.GASKET, WATERPUMP CVR.
-
75630920 COVER-WATERPUMP, SNOW HI-FLOWCOVER-WATERPUMP, SNOW HI-FLOW
-
87516822 SCREWSCREW
-
97555977 WASHER, THRUSTWASHER, THRUST
-
105135221 SHAFT-GEAR, WATER/OIL NOTCH DRSHAFT-GEAR, WATER/OIL NOTCH DR
-
115412942 O-RING .801X.941X.070O-RING .801X.941X.070
-
125135220 BEARING-PUMP SHFT, FLANGE 24DIABEARING-PUMP SHFT, FLANGE 24DIA
-
132520552 ASM-OIL PUMP, 6 OUTLET 600SDIASM-OIL PUMP, 6 OUTLET 600SDI
-
147080603 CLAMPCLAMP
-
158450061-600 LINE, FUEL, 3MMX7MMLINE, FUEL, 3MMX7MM
-
167518637 SCR-M6X1.0X16.0MM HEX-FL-Y/DSCR-M6X1.0X16.0MM HEX-FL-Y/D
-
177517277 SCREWSCREW
