CARGO RACK для Polaris TRAIL TOURING FLEET (S09NT5BSF) - 2009 года выпуска
-
№АртикулНазвание
-
12875964 BAG,2 UP TOURINGBAG,2 UP TOURING
-
27512076 SCREWSCREW
-
47670125 FASTNER-PUSH-ON CLIP,.250FASTNER-PUSH-ON CLIP,.250
-
55246523 BAIL-TRUNK LOCKBAIL-TRUNK LOCK
-
67661637 RIVET,INTERLOCK,ZRIVET,INTERLOCK,Z
-
75435128-070 SKIRT-SNOW,EDGE, LEFT HAND, BLACKSKIRT-SNOW,EDGE, LEFT HAND, BLACK
-
75435129-070 SKIRT-SNOW,EDGE, RIGHT HAND, BLACKSKIRT-SNOW,EDGE, RIGHT HAND, BLACK
-
75412449 PLUG-HANDWARMER SWITCH (RH ONLY)PLUG-HANDWARMER SWITCH (RH ONLY)
-
87621467 RIVET, BLINDRIVET, BLIND
-
95410582 PLUG,CATCH HOLEPLUG,CATCH HOLE
-
107517916 SCR-1/4-20X3/4-TR/TX/TAP-MSCR-1/4-20X3/4-TR/TX/TAP-M
Все узлы модели:
- AIR INTAKE SYSTEM
- BACKREST W/GRAB HANDLE
- BATTERY BOX
- BLOWER HOUSING W/FAN DUCT
- BRAKE ASSEMBLY
- BULKHEAD AND TUNNEL
- BUMPER/HITCH FLAP
- CARBURETOR W/CHOKE
- • CARGO RACK
- CHAINCASE ASSEMBLY
- CLUTCH - PRIMARY
- CLUTCH - SECONDARY
- CONSOLE
- CRANKCASE ASSEMBLY
- CYLINDER ASSEMBLY
- DECALS
- DRIVE SHAFT ASSY.
- ELECTRICAL - IGNITION SYSTEM
- ENGINE MOUNTING W/ SHORT BLOCK
- EXHAUST SYSTEM
- FUEL PUMP
- FUEL TANK W/FUEL LINES
- HANDLEBAR W/THROTTLE ASSEMBLY
- HEADLIGHT AND TAILLIGHT
- HOOD - FOAM/FOIL
- HOOD ASSEMBLY W/ HEADLIGHT COVER
- HOOD ASSEMBLY W/ WINDSHIELD
- NOSEPAN AND FOIL
- NOSEPAN/BUMPER
- OIL PUMP
- OIL TANK
- PISTON W/ BEARING
- RECOIL STARTER W/BLOWER HOUSING
- SEAT W/ TAILLIGHT
- SHOCK TOWERS AND PAN BRACE
- SKI ASSEMBLY
- SPEEDOMETER W/INDICATOR LIGHTS
- STARTING MOTOR ASSEMBLY
- STEERING - LOWER
- STEERING POST - HOOP
- SUSPENSION - FRONT SHOCK
- SUSPENSION - FRONT TORQUE ARM ASSEMBLY
- SUSPENSION - IFS SHOCK
- SUSPENSION - RADIUS RODS AND TRAILING ARM 1
- SUSPENSION - RADIUS RODS AND TRAILING ARM 2
- SUSPENSION - RAIL MOUNTING
- SUSPENSION - REAR
- SUSPENSION - REAR SHOCK TRACK
- SUSPENSION - REAR TORQUE ARM ASSEMBLY
- TOOL KIT W/OWNERS MANUAL
- WIRING HARNESS
