FRONT GEARCASE INTERNALS для Polaris RANGER CREW 570-4 (SAGE GREEN) [R16RNA57A1] - 2016 года выпуска
-
№АртикулНазвание
-
11333285 ASSY, FRONT GEARCASE (INCL 2-13)ASSY, FRONT GEARCASE (INCL 2-13)
-
23235168 ASSY, COVER OUTPUT (INCL O-RING, DOWEL PIN, OIL SEAL, COVER, CONNECTOR ASSY, BACKLASH SPACER, 4WD COIL, GROMMET AND HEAT SHRINK TUBING)ASSY, COVER OUTPUT (INCL O-RING, DOWEL PIN, OIL SEAL, COVER, CONNECTOR ASSY, BACKLASH SPACER, 4WD COIL, GROMMET AND HEAT SHRINK TUBING)
-
33235169 KIT, HUB ASSY (INCL BUSHING, HUB SUB. ASSY AND NYLON SPACER)KIT, HUB ASSY (INCL BUSHING, HUB SUB. ASSY AND NYLON SPACER)
-
43235170 KIT, FASTENER (INCL ALL FASTENERS)KIT, FASTENER (INCL ALL FASTENERS)
-
53235171 KIT, SEAL REPAIR (INCL ALL SEALS)KIT, SEAL REPAIR (INCL ALL SEALS)
-
63235485 PLATE, ARMATUREPLATE, ARMATURE
-
73235174 BEARING, PINION (INCL ALL BEARINGS)BEARING, PINION (INCL ALL BEARINGS)
-
83234393 KIT, ROLLER (INCL COMPLETE SET OF ROLLER)KIT, ROLLER (INCL COMPLETE SET OF ROLLER)
-
93235261 ASSY, ROLL CAGE ZN (INCL ROLL CAGE AND SPRING WIRE FOR H-CLIP)ASSY, ROLL CAGE ZN (INCL ROLL CAGE AND SPRING WIRE FOR H-CLIP)
-
93235262 ASSY, ROLL CAGE ALUM (HIGH PERFORMANCE ACCESSORY W/CLIP SET)ASSY, ROLL CAGE ALUM (HIGH PERFORMANCE ACCESSORY W/CLIP SET)
-
103235440 KIT, GEARCASE ASSY (INCL HOSE FITTING, BUSHING, SEAL, GEARCASE, FILL PLUG AND DRAIN PLUG)KIT, GEARCASE ASSY (INCL HOSE FITTING, BUSHING, SEAL, GEARCASE, FILL PLUG AND DRAIN PLUG)
-
112203738 PLUG, DRAINPLUG, DRAIN
-
122203739 PLUG, FILLPLUG, FILL
-
133235636 KIT, GEAR HOUSING AND PINION (INCL RING GEAR ASSY, PINION, BEARING, INTERNAL RING AND SHAFT RING)KIT, GEAR HOUSING AND PINION (INCL RING GEAR ASSY, PINION, BEARING, INTERNAL RING AND SHAFT RING)
-
143235712 KIT, SPRING (INCL TORSION SPRING AND SPRINT RETAINER ASSY)KIT, SPRING (INCL TORSION SPRING AND SPRINT RETAINER ASSY)
