FRONT SHOCK W/ MOUNTING - INTERNAL для Polaris GENERAL 4 1000 EPS RIDE COMMAND EDITION MATTE SUNSET RED (R18RHK99BS) - 2018 года выпуска
-
№АртикулНазвание
-
-7044687 SHOCK-FRONT, PIGGYBK, LEFT HANDSHOCK-FRONT, PIGGYBK, LEFT HAND
-
-7044688 SHOCK-FRONT, PIGGYBK, RIGHT HANDSHOCK-FRONT, PIGGYBK, RIGHT HAND
-
11501028 BUMPER, B/O SHAFTBUMPER, B/O SHAFT
-
21501010 BUSHING, EYELETBUSHING, EYELET
-
31500842 NUTNUT
-
41501011 SCREW, #4, SS PANSCREW, #4, SS PAN
-
51501012 DECAL, PERF SERIESDECAL, PERF SERIES
-
61501013 DECAL, RESERVOIRDECAL, RESERVOIR
-
71501105 DECAL, BASE VALVEDECAL, BASE VALVE
-
81500623 O-RINGO-RING
-
91500510 O-RINGO-RING
-
101501014 SEAL, WEATHERSEAL, WEATHER
-
111500236 RING,RETAININGRING,RETAINING
-
121501015 RING, RET. WIRERING, RET. WIRE
-
131501100 CAP, BEARINGCAP, BEARING
-
141501029 BODY CAP (USED WITH 7044687) (LEFT)BODY CAP (USED WITH 7044687) (LEFT)
-
141501030 BODY CAP (USED WITH 7044688) (RIGHT)BODY CAP (USED WITH 7044688) (RIGHT)
-
161501108 KNOB, DAMP ADJ.KNOB, DAMP ADJ.
-
171501032 EYELET PARTSEYELET PARTS
-
181501087 SLEEVE,.39IDX1.18LG 214-49-003SLEEVE,.39IDX1.18LG 214-49-003
-
191501088 SPACER,.150 TLG 214-50-015SPACER,.150 TLG 214-50-015
-
201501023 RESERVOIR, 5"THD 227-41-050-4RESERVOIR, 5"THD 227-41-050-4
-
211501033 SHAFTSHAFT
-
221500872 RING,PRELOAD,BACK (234-00-275)RING,PRELOAD,BACK (234-00-275)
-
231500873 RING,PRELOAD (234-00-276)RING,PRELOAD (234-00-276)
-
241500161 SCREW/O-RING ASM.SCREW/O-RING ASM.
-
251501026 ASM., PISTON, FLOATASM., PISTON, FLOAT
-
261501187 DAMPING ADJUSTMENT ASSEMBLYDAMPING ADJUSTMENT ASSEMBLY
-
271501185 ASM., BEARING, .62SHAFTASM., BEARING, .62SHAFT
-
281501027 ASM., END CAP, RESERVOIRASM., END CAP, RESERVOIR
