FENDER - REAR (CALIF ONLY) для Suzuki VZR1800 L1 - 2011 года выпуска
-
№АртикулНазвание
-
163110-48G00-YKZ FENDER, REAR (BLUE) (YKZ)FENDER, REAR (BLUE) (YKZ)
-
163110-48G00-YVB FENDER, REAR (BLACK) (YVB)FENDER, REAR (BLACK) (YVB)
-
268641-19F00-YD8 EMBLEM (SILVER)EMBLEM (SILVER)
-
363117-39G00 CUSHIONCUSHION
-
494484-24F00 NUTNUT
-
509139-06139 SCREW (6X16)SCREW (6X16)
-
609180-06286 SPACER (6.5X10X9.4)SPACER (6.5X10X9.4)
-
709320-10045 CUSHIONCUSHION
-
809139-06190 BOLT (6X20)BOLT (6X20)
-
909320-09016 CUSHIONCUSHION
-
1063171-48G01-YKZ COVER, REAR FENDER RIGHT HAND (BLUE) (YKZ)COVER, REAR FENDER RIGHT HAND (BLUE) (YKZ)
-
1063171-48G01-YVB COVER, REAR FENDER RIGHT HAND (BLACK) (YVB)COVER, REAR FENDER RIGHT HAND (BLACK) (YVB)
-
1163181-48G01-YKZ COVER, REAR FENDER LEFT HAND (BLUE) (YKZ)COVER, REAR FENDER LEFT HAND (BLUE) (YKZ)
-
1163181-48G01-YVB COVER, REAR FENDER LEFT HAND (BLACK) (YVB)COVER, REAR FENDER LEFT HAND (BLACK) (YVB)
-
1215439-70G10 CUSHION, RIGHT HANDCUSHION, RIGHT HAND
-
1347161-19C00 CUSHION, LEFT HANDCUSHION, LEFT HAND
-
1444276-29G00 CUSHION, COVERCUSHION, COVER
-
1509409-06314-5PK CLIP (BLACK)CLIP (BLACK)
-
1609320-08028 CUSHIONCUSHION
-
1703541-0516A SCREWSCREW
