MAGNETO для Tohatsu M4C - 2007 года выпуска
-
№АртикулНазвание
-
1369-06001-1 Flywheel CupFlywheel Cup
-
2369-06021-0 Exciter CoilExciter Coil
-
3921521-6520 ScrewScrew
-
4369-06915-0 Clamp, 4.2-3-8Clamp, 4.2-3-8
-
5921521-6408 ScrewScrew
-
6369-06060-1 C. D. UnitC. D. Unit
-
73H6-06907-0 Rubber Damper “B”Rubber Damper “B”
-
83H6-06906-0 Rubber Damper “A”Rubber Damper “A”
-
9369-06050-2 Ignition CoilIgnition Coil
-
9-13M2-06291-0 * Plug Cap* Plug Cap
-
9-23M2-06926-0 * Plug Cap Terminal* Plug Cap Terminal
-
9-33C7-06921-0 * Plug Cap ( with Resistance)* Plug Cap ( with Resistance)
-
10910103-5620 BoltBolt
-
11369-06071-0 Pulser CoilPulser Coil
-
12921521-6412 ScrewScrew
-
13369-06908-0 Pulser Coil GrommetPulser Coil Grommet
-
143D5-06870-0 Stop SwitchStop Switch
-
14-1353-06821-0 * Stop Switch Lanyard* Stop Switch Lanyard
-
15369-00132-0 Magneto Nut (12P-1.25)Magneto Nut (12P-1.25)
-
16940121-1200 WasherWasher
-
17951503-0318 Split Pin, 3-18Split Pin, 3-18
-
1369-06001-1 Flywheel CupFlywheel Cup
-
2369-06021-0 Exciter CoilExciter Coil
-
3921521-6520 ScrewScrew
-
4369-06915-0 Clamp, 4.2-3-8Clamp, 4.2-3-8
-
5921521-6408 ScrewScrew
-
6369-06060-1 C. D. UnitC. D. Unit
-
73H6-06907-0 Rubber Damper “B”Rubber Damper “B”
-
83H6-06906-0 Rubber Damper “A”Rubber Damper “A”
-
9369-06050-2 Ignition CoilIgnition Coil
-
9-13M2-06291-0 * Plug Cap* Plug Cap
-
9-23M2-06926-0 * Plug Cap Terminal* Plug Cap Terminal
-
9-33C7-06921-0 * Plug Cap ( with Resistance)* Plug Cap ( with Resistance)
-
10910103-5620 BoltBolt
-
11369-06071-0 Pulser CoilPulser Coil
-
12921521-6412 ScrewScrew
-
13369-06908-0 Pulser Coil GrommetPulser Coil Grommet
-
143D5-06870-0 Stop SwitchStop Switch
-
14-1353-06821-0 * Stop Switch Lanyard* Stop Switch Lanyard
-
15369-00132-0 Magneto Nut (12P-1.25)Magneto Nut (12P-1.25)
-
16940121-1200 WasherWasher
-
17951503-0318 Split Pin, 3-18Split Pin, 3-18
