PISTON CRANKSHIFT для Tohatsu M25C3 - 2009 года выпуска
-
№АртикулНазвание
-
13P1-00030-0 Crank Shaft Ass'v (New）
# 032359XD〜 Clockwise ScrewCrank Shaft Ass'v (New）
# 032359XD〜 Clockwise Screw -
1346-00030-1 Crank Shaft Ass'v (Old）
〜# 028071XD Counterclockwise ScrewCrank Shaft Ass'v (Old）
〜# 028071XD Counterclockwise Screw -
1-13P1-00031-0 * Crank Shaft "A” (New）
# 032359XD〜 Clockwise Screw* Crank Shaft "A” (New）
# 032359XD〜 Clockwise Screw -
1-1346-00031-0 * Crank Shaft "A” (Old）
〜# 028071XD Counterclockwise Screw* Crank Shaft "A” (Old）
〜# 028071XD Counterclockwise Screw -
1-2346-00032-0 * Crank Shaft "B"* Crank Shaft "B"
-
1-3346-00033-0 * Crank Shaft "C”* Crank Shaft "C”
-
1-4346-00034-0 * Crank Shaft "D”* Crank Shaft "D”
-
1-5334-00061-0 * Crank Pin* Crank Pin
-
1-63J2-00114-0 * Ball Bearing, 6305
30A3 # 29197〜 25C2# 38254〜* Ball Bearing, 6305
30A3 # 29197〜 25C2# 38254〜 -
1-7346-00051-1 * Labyrinth Packing
30A3# 33181〜 25C2# 45535〜* Labyrinth Packing
30A3# 33181〜 25C2# 45535〜 -
1-8951407-0308 * Spring Pin, 3-8
30A3# 33181〜 25C2# 45535〜* Spring Pin, 3-8
30A3# 33181〜 25C2# 45535〜 -
1-9336-00040-1 * Connecting Rod* Connecting Rod
-
1-10356-00043-0 * Needle Bearing, 20-28-18* Needle Bearing, 20-28-18
-
2345-00113-0 Ball Bearing, 3026Ball Bearing, 3026
-
33J2-00114-0 Ball Bearing, 6305
30A3 # 29197〜 25C2# 38254〜Ball Bearing, 6305
30A3 # 29197〜 25C2# 38254〜 -
4945107-2500 ClipClip
-
5346-00116-0 Spacer, 25.2-34-1.6Spacer, 25.2-34-1.6
-
6332-00143-0 Shim, 25.5-33-0.2Shim, 25.5-33-0.2
-
7346-00001-3 Piston (Std)Piston (Std)
-
7346-00004-3 Piston (0.5mm O/S)
OptionPiston (0.5mm O/S)
Option -
8346-00011-0 Piston Ring (Std)Piston Ring (Std)
-
8346-00014-0 Piston Ring (0.5mm O/S)
OptionPiston Ring (0.5mm O/S)
Option -
9345-00042-0 Needle Bearing, 17-21-27Needle Bearing, 17-21-27
-
103C8-00021-0 Piston PinPiston Pin
-
11334-00024-1 Piston Pin ClipPiston Pin Clip
-
12334-00131-0 Magneto KeyMagneto Key
